Siemens 6AV2124-0XC02-0AX1 TP2200 Comfort 21.5 Inch TFT HMI Panel

Elevate Your Industrial Control Systems with Cutting-Edge Visualization Technology

Overview:

The Siemens 6AV2124-0XC02-0AX1 TP2200 Comfort 21.5 inch TFT HMI Panel represents the pinnacle of user interface technology for industrial automation. Designed to enhance operational efficiency and provide seamless interaction with complex control systems, this advanced Human-Machine Interface (HMI) combines a high-resolution TFT display with intuitive touch functionality, making it an indispensable tool for modern industrial environments.

Key Features:

• 21.5-Inch TFT Display: The TP2200 Comfort features a generous 21.5-inch TFT (Thin Film Transistor) display with full HD resolution (1920 x 1080 pixels), offering crisp, clear visuals and an expansive workspace for detailed graphics and complex control panels. The wide screen ensures easy readability from various angles, enhancing user experience and reducing eye strain during prolonged operation.

• Touchscreen Interface: Equipped with a highly responsive multi-touch screen, the TP2200 Comfort supports gesture-based inputs and ensures smooth navigation through intricate system controls. The capacitive touch technology allows for precise and reliable interaction, even in challenging industrial environments.

• Robust Performance: Powered by a high-performance processor and ample memory, this HMI panel delivers swift processing speeds and seamless operation of advanced graphical user interfaces (GUIs). It supports complex applications and high-speed data handling, ensuring consistent performance under demanding conditions.

• Versatile Connectivity: The TP2200 Comfort provides a range of connectivity options, including Ethernet, USB, and serial ports, facilitating easy integration with various PLCs, SCADA systems, and other industrial equipment. This versatility ensures compatibility with a broad spectrum of automation systems and simplifies system configuration.

• Enhanced Durability: Built to withstand the rigors of industrial environments, the TP2200 Comfort features a rugged design with an IP65-rated front panel, offering protection against dust, moisture, and harsh operational conditions. Its durable construction ensures long-term reliability and minimizes maintenance requirements.

• User-Friendly Programming: Siemens' powerful and intuitive software tools, such as WinCC Comfort, enable straightforward configuration and customization of the HMI interface. Users can easily design and deploy user-friendly screens, create dynamic visuals, and implement complex control logic with minimal programming effort.

• Advanced Functionality: The TP2200 Comfort supports advanced features such as multi-language capability, alarm handling, and data logging. These functionalities enhance operational efficiency, improve decision-making, and provide comprehensive insights into system performance.

Applications:

Ideal for a wide range of industrial applications, the Siemens 6AV2124-0XC02-0AX1 TP2200 Comfort 21.5 inch TFT HMI Panel is well-suited for use in manufacturing, process control, energy management, and other sectors where precision and reliability are critical. Its advanced display and touch capabilities make it an excellent choice for complex control systems requiring intuitive and responsive user interfaces.

Specifications:

• Model: Siemens 6AV2124-0XC02-0AX1
• Display Size: 21.5 inches
• Resolution: 1920 x 1080 pixels
• Touch Technology: Capacitive Multi-Touch
• Connectivity: Ethernet, USB, Serial Ports
• Protection Class: IP65 (Front Panel)
• Operating Temperature Range: 0°C to +55°C
• Software Compatibility: WinCC Comfort

Conclusion:

The Siemens 6AV2124-0XC02-0AX1 TP2200 Comfort 21.5 inch TFT HMI Panel sets a new standard in industrial interface technology. With its exceptional display quality, responsive touch functionality, and robust performance, it delivers an unparalleled user experience and supports efficient and effective control of complex systems. Invest in the TP2200 Comfort to enhance your operational capabilities and streamline your industrial processes.

For more information or to request a quote, contact us today.

Siemens 6AV2124-0XC02-0AX1 TP2200 Comfort 21.5 inch TFT widescreen display, 16 Mio colors

Display 21.5 inch TFT widescreen display, 16 Mio colors

Resolution 1920 x 1080

Control elements Touch screen

User memory 24 MB

Interfaces

2 x RJ 45 for PROFINET (with integrated switch)

1 x RJ 45 Ethernet for PROFINET (gigabit capable)

1 x RS 485/422 for PROFIBUS/MPI

2 x USB-host, 1 x USB- device

2 x SD card slot

Degree of protection IP 65, NEMA 4x (front if mounted) / IP 20 rear

Installation cutout 542 x 362 mm (W x H)

Front panel 560 x 380 mm (W x H)

Device depth 75 mm

Software functions

Configuration software

WinCC Comfort (TIA Portal) or higher

Messages 6000

Message classes 32

Process pictures 750

Variables 4096

Vector graphics x

Bar graphics x

Curve diagrams f (t), f (x)

Recipes 500

Archiving 200

Visual Basic Scripts 200

Article No.: 6AV2124-0XC02-0AX1
