• Mitsubishi FX5-32ET/DSS FX5;I/O Extension Module

Mitsubishi FX5-32ET/DSS FX5 I/O Extension Module

Overview

The Mitsubishi FX5-32ET/DSS I/O Extension Module is an advanced component designed to expand the I/O capabilities of Mitsubishi FX5 series programmable logic controllers (PLCs). Engineered for precision and reliability, this module enhances system flexibility and scalability in various industrial automation applications.

Key Features

  • Extended I/O Capacity: The FX5-32ET/DSS provides 32 additional I/O points, including 16 input and 16 output channels. This allows for the seamless integration of more devices and sensors, accommodating the growing demands of complex automation tasks.
  • Digital Input/Output: Equipped with high-performance digital I/O, this module supports a range of input and output configurations, ensuring compatibility with a broad spectrum of industrial equipment.
  • Compact Design: The module’s compact form factor ensures easy installation in tight control panels, optimizing space without compromising performance.
  • High-Speed Operation: Designed for rapid data processing, the FX5-32ET/DSS delivers fast response times, enhancing the efficiency of control processes and minimizing downtime.
  • Enhanced Reliability: Built to withstand harsh industrial environments, this module offers robust protection against electrical noise and interference, ensuring stable operation in challenging conditions.
  • Easy Integration: Seamlessly integrates with Mitsubishi FX5 PLCs, facilitating straightforward setup and configuration. The module supports various communication protocols for effortless system connectivity.

Technical Specifications

  • Input Channels: 16 digital inputs
  • Output Channels: 16 digital outputs
  • Input Type: Sink/source type
  • Output Type: Transistor output
  • Input Voltage Range: 24V DC
  • Output Voltage Range: 24V DC
  • Current Rating: 0.5A per channel
  • Operating Temperature: 0°C to 55°C
  • Storage Temperature: -25°C to 70°C
  • Dimensions: [Insert dimensions here]
  • Weight: [Insert weight here]

Applications

The Mitsubishi FX5-32ET/DSS I/O Extension Module is ideal for a wide range of industrial automation applications, including:

  • Manufacturing: Expanding the I/O capacity of control systems for enhanced machine and process control.
  • Processing: Facilitating the integration of additional sensors and actuators in automated processing systems.
  • Logistics: Enhancing control and monitoring capabilities in automated material handling and distribution systems.

Benefits

  • Scalability: Easily expand your automation system to meet evolving operational requirements.
  • Flexibility: Accommodates diverse industrial applications with its versatile I/O configurations.
  • Efficiency: Improve system performance and responsiveness with high-speed operation.

Conclusion

The Mitsubishi FX5-32ET/DSS FX5 I/O Extension Module is a vital addition to any Mitsubishi FX5 PLC system, offering expanded I/O capabilities, robust performance, and reliable operation. Ideal for demanding industrial environments, this module supports efficient and scalable automation solutions. Enhance your control systems with the Mitsubishi FX5-32ET/DSS and experience unparalleled flexibility and performance.


Feel free to adjust any specifics or add more technical details as needed!

Mitsubishi FX5-32ET/DSS FX5;I/O Extension;DC;16 Inputs;16 Transistor Outputs;source

  DIGITAL I/O MODULE
Type FX5
Power Supply (V) 24
Current Type DC
Occupied I/O Points on PLC 32
Integrated Digital Inputs 16
Integrated Digital Outputs 16
Output Type TRANSISTOR
Output Logic SOURCE
PRODUCT DIMENSIONS & WEIGHT
Width (mm) 150
Height (mm) 90
Depth (mm) 83
Weight (kg) 0,65
ORDER CODES
European Order Code 297441
Global Order Code 09U407
CLASSIFICATION DATA
Product hierarchy IAD21702
Class Description FA-COM PLC: Digital I/O Module
External Material Group Standard Material
AVAILABILITY
Logistic Class A
PACKAGING DIMENSIONS & WEIGHT
Gross Weight 0.693  KG
Volume 2.244  CDM
Length 17 CM
Width 12 CM
Height 11 CM
COMMODITY / IMPORT CODE
Commodity Code 85389099
Country of Origin JP
CAMPAIGNS
Selling Status Standard
ENVIRONMENTAL

REACH Limit Exceeded NO
Dangerous Goods Regulations NO

Mitsubishi FX5-32ET/DSS FX5;I/O Extension Module

  • Brand: Mitsubishi
  • Product Code: FX5-32ET/DSS
  • Availability: 1000

Tags: Mitsubishi FX5-32ET/DSS, I/O Extension, FX5 PLC, High-Speed I/O, Automation Module, Industrial Automation, Mitsubishi PLC Expansion, Digital I/O Module
