Schneider HMIBMP0I74D2001 Modular Box PC HMIBM Performance DC Base Unit - 8GB RAM, 2 Slots
Elevate your industrial automation and control systems with the Schneider HMIBMP0I74D2001 Modular Box PC. Engineered for robust performance and flexibility, this high-performance DC base unit is a cornerstone of Schneider Electric's HMIBM Performance series, designed to meet the rigorous demands of modern industrial environments.
Key Features:
Powerful Performance: Equipped with 8GB of high-speed RAM, the HMIBMP0I74D2001 ensures seamless operation and swift data processing. This ample memory capacity supports complex applications and multitasking without compromising performance.
Expandable Memory: The unit features 2 RAM slots, allowing for future upgrades to accommodate evolving system requirements and enhance overall processing capabilities.
Modular Design: The HMIBMP0I74D2001 is built with a modular architecture, providing exceptional scalability and customization. Its design facilitates easy integration with various modules and peripherals, ensuring compatibility with a wide range of industrial applications.
Reliability and Durability: Constructed with premium materials and advanced engineering, this base unit delivers exceptional durability and reliability. It is designed to operate efficiently in challenging industrial environments, withstanding vibrations, shocks, and temperature fluctuations.
Enhanced Connectivity: This Modular Box PC is equipped with multiple connectivity options, enabling seamless communication with other system components. It supports a range of industrial protocols and interfaces, ensuring versatile integration into existing systems.
Compact and Efficient: The compact form factor of the HMIBMP0I74D2001 allows for flexible installation in space-constrained environments. Its efficient design minimizes footprint while maximizing performance.
Industry-Leading Support: Schneider Electric provides comprehensive support and service for the HMIBMP0I74D2001, ensuring that your system remains operational and efficient throughout its lifecycle.
Applications:
The Schneider HMIBMP0I74D2001 is ideal for various industrial applications, including:
- Automation and control systems
- Manufacturing execution systems (MES)
- Data acquisition and processing
- Industrial IoT (IIoT) solutions
- Real-time monitoring and diagnostics
Technical Specifications:
- Model: Schneider HMIBMP0I74D2001
- RAM: 8GB
- RAM Slots: 2
- Series: HMIBM Performance DC Base Unit
- Design: Modular
- Connectivity: Multiple industrial interfaces
- Durability: Designed for industrial environments
Optimize your industrial operations with the Schneider HMIBMP0I74D2001 Modular Box PC. Its advanced performance, modular flexibility, and durable design make it a valuable asset for any industrial automation setup.
For more information or to request a quote, contact us today.
| range of product |
Magelis iPC
|
|
|---|---|---|
| product or component type |
Modular box PC
|
|
| device short name |
Modular BOX PC Performance
|
|
| processor name |
Intel Core i7 4650U 1.7 GHz turbo boost at 3.3 GHz
|
|
| chipset type |
Intel QM87
|
|
| free slots |
1 CFast
1 mSATA 2 Internal SATA HDD/SSD with slide-in HMIYMADSDD1 to mount . hot swap RAID with Intel Rapid Storage Technology |
|
| video controller type |
Intel HD Graphics 5000
|
|
| software package |
EcoStruxture secure connect advisor annual subscription cyber
security license not included
EcoStruxure operator terminal expert run time HMI license not included EcoStruxure machine SCADA expert run time HMI/SCADA on configured offer only EcoStruxure augmented operator advisor server augmented operator license not included Node-RED and system nodes restore IIoT Wiring Operating System Restore McAfee white listing Installer cyber security license not included |
| range compatibility |
Modular Display HMIDM
IDisplay |
|
|---|---|---|
| accessory / separate part destination |
PC panel on HMIDM modular display
|
|
| mounting location |
Wall mounting
Flat mounting Book mounting |
|
| memory description |
Internal 512 kB MRAM
Internal 8 GB RAM DDR3 not expandable |
|
| number of slots |
2 mini PCI Express full-size
|
|
| display resolution |
3200 x 2000 pixels at 60 Hz
|
|
| watchdog timer |
1...255 ms
|
|
| type of cooling |
Fanless
Fan required to mount PCI/PCIe cards above 3 W |
|
| electrical connection |
Connector SMA for 3 on top
Screw connector pin for 1 way ground on bottom |
|
| integrated connection type |
Display port with 1 on bottom
Display port with 1 on front COM1 serial link for battery backup with 1 male SUB-D 9 RS232/422/485 on bottom USB 2.0 port with 2 USB type A, transmission rate: 480 Mbit/s on bottom USB 3.0 port with 2 USB type A, transmission rate: 5 Gbit/s on bottom Ethernet with 2 RJ45 I210, supporting IEEE1588, transmission rate: 10/100/1000 Mbps on bottom TPM connector Ver 1.2 for cyber security - hardware encryption TPM module HMIYMINATPM201 to be installed/default installed on mother board |
|
| [Us] rated supply voltage |
100...240 V AC power supply with additional adaptor HMIYMMAC1
24 V DC power supply |
|
| supply voltage limits |
18...36 V
|
|
| inrush current |
8.9 A
|
|
| power consumption in W |
40 W box
44 W with 4:3 12" Display HMIDM6421 43 W with Wide 12" Display HMIDM6521 45 W with 4:3 15" Display HMIDM7421 46 W with Wide 15" Display HMIDM7521 48 W with Wide 19" Display HMIDM9521 51 W with Wide 22" Display HMIDMA521 |
|
| control type |
ON/OFF button
|
|
| depth |
65.2 mm
|
|
| height |
207 mm
|
|
| width |
254 mm
|
|
| product weight |
3.1 kg
|
|
| main type |
Performance
|
|
| number of slots available for expansion |
2 mini PCIe
|
| standards |
EN 61131-2
EN 55011 class A group 1 EN 61000-6-4 FCC Part 15 UL 61010 |
|
|---|---|---|
| product certifications |
CCC
EAC ATEX RCM Marine GL Bridge IEC Ex hazardous locations 3GD zone 2/22 CULus CE CULus CSA 22-2 No 142 CULus HazLoc Class I Division 2 ANSI/ISA 12-12-01 CULus HazLoc Class I Division 2 CSA 22-2 No 213 |
|
| quality labels |
CE
|
|
| directives |
2006/95/EC - low voltage directive
2004/108/EC - electromagnetic compatibility |
|
| IP degree of protection |
IP40 conforming to IEC 60529
|
|
| electromagnetic compatibility |
Conducted and radiated emissions class A EN 55022
Immunity to high frequency interference IEC 61000-4 Disturbing field emission class A EN 55011 |
|
| ambient air temperature for storage |
-30...70 °C conforming to IEC 60068-2-2
-30...70 °C conforming to IEC 60068-2-14 |
|
| relative humidity |
10...95 % non-condensing conforming to EN/IEC 60068-2-30
|
|
| ambient air temperature for operation |
0...55 °C (by default) conforming to EN/IEC 60068-2-2
0...50 °C flat mounting conforming to EN/IEC 60068-2-2 0...45 °C on PCI/PCIe HMIDM modular display with HDD conforming to EN/IEC 60068-2-2 0...40 °C flat mounting on HDD conforming to EN/IEC 60068-2-2 0...40 °C flat mounting on mini PCIe conforming to EN/IEC 60068-2-2 0...40 °C flat mounting on PCI/PCIe conforming to EN/IEC 60068-2-2 0...50 °C conforming to 2 on mini PCIe HMIDM modular display conforming to EN/IEC 60068-2-2 |
|
| operating altitude |
2000 m conforming to IEC 60664-1
|
|
| vibration resistance |
1 gn 5...500 Hz HDD
2 gn 5...500 Hz SSD or CFast |
