Schneider HMIDT642 12.1" Touch Smart Display XGA – Advanced Human-Machine Interface for Precision Control
Elevate your operational efficiency with the Schneider HMIDT642, a state-of-the-art 12.1" Touch Smart Display engineered to deliver superior performance in industrial environments. This XGA touch display is designed for seamless integration into various automation systems, offering intuitive interaction and robust functionality to enhance your control and monitoring processes.
Key Features:
1. High-Resolution Display: The Schneider HMIDT642 features a 12.1" XGA (1024 x 768) LCD screen that provides crystal-clear visuals and exceptional detail. This high-resolution display ensures that critical data and process information are presented with remarkable clarity, enabling operators to make informed decisions swiftly.
2. Enhanced Touch Interface: Equipped with a responsive and durable capacitive touch screen, the HMIDT642 ensures precise input control and a user-friendly interface. Its multi-touch capabilities allow for intuitive gesture-based navigation, making complex operations simpler and more efficient.
3. Robust Industrial Design: Built to withstand harsh industrial environments, the HMIDT642 boasts an IP65-rated front panel that offers superior protection against dust and water ingress. This rugged design ensures reliable performance in demanding conditions, reducing downtime and maintenance costs.
4. Versatile Connectivity: The HMIDT642 supports a range of connectivity options, including Ethernet, USB, and serial ports, enabling seamless integration with existing automation systems and facilitating smooth data exchange. Its compatibility with various communication protocols ensures flexibility in diverse application scenarios.
5. Advanced Functionality: Featuring Schneider Electric's latest software advancements, the HMIDT642 supports comprehensive HMI applications, including real-time data visualization, alarm management, and trend analysis. This functionality allows for detailed monitoring and control of your processes, enhancing operational efficiency and productivity.
6. Easy Integration and Configuration: With user-friendly configuration tools and extensive support for Schneider Electric’s software ecosystem, the HMIDT642 integrates effortlessly into your automation infrastructure. Its straightforward setup process and customizable interfaces facilitate rapid deployment and adaptation to specific operational needs.
7. Reliable Performance: Designed for continuous operation, the HMIDT642 is engineered to deliver consistent performance with minimal maintenance. Its high-quality components and advanced thermal management ensure long-term reliability, making it an ideal choice for critical applications.
Applications:
The Schneider HMIDT642 12.1" Touch Smart Display is ideal for use in a wide range of industrial applications, including manufacturing processes, process control systems, and facility management. Its advanced features and robust design make it a valuable asset in environments where precision, durability, and ease of use are paramount.
Why Choose Schneider HMIDT642?
Choosing the Schneider HMIDT642 means investing in a high-performance HMI solution that combines cutting-edge technology with industrial-grade durability. This touch smart display is engineered to enhance your operational capabilities, offering a superior user experience and reliable performance in demanding environments.
Optimize your industrial operations with the Schneider HMIDT642 – where precision meets innovation.
SEO Keywords: Schneider HMIDT642, 12.1" Touch Smart Display, XGA Touch Screen, Industrial HMI Display, Schneider Electric Touch Display, High-Resolution HMI, Rugged Industrial Display, Capacitive Touch Screen HMI, Advanced Human-Machine Interface.
range of product |
Magelis GTU
|
|
---|---|---|
product or component type |
Flat screen
|
|
terminal type |
Touchscreen display
|
|
integrated connection type |
USB 2.0 type A
USB 2.0 type mini B |
pixel resolution |
1024 x 600
|
|
---|---|---|
touchscreen resolution |
1024 x 600
|
|
function available |
Brightness sensor
|
|
[Us] rated supply voltage |
12...24 V DC power supply
|
|
supply voltage limits |
10.8...28.8 V
|
|
power consumption in W |
21 W
|
|
display size |
12.1 inch
|
|
display type |
Colour TFT LCD
|
|
display resolution |
1024 x 768 pixels XGA
|
|
display colour |
16 million colours
|
|
backlight lifespan |
50000 hours
|
|
touch panel |
Multi touch analogue resistive
|
|
type of installation |
Indoor installation
|
|
type of cooling |
Natural convection
|
|
inrush current |
30 A
|
|
cut-out dimensions |
301.5 (+ 1/- 0) x 227.5 (+ 1/- 0) mm
|
|
width |
315 mm
|
|
height |
241 mm
|
|
depth |
67 mm
|
|
product weight |
3 kg
|
IP degree of protection |
IP66 (front panel)
IP67 (front panel) |
|
---|---|---|
NEMA degree of protection |
NEMA 4X (front panel)
|
|
standards |
CSA C22.2 No 142
ANSI/ISA 12-12-01 IEC 61132-2 CSA C22.2 No 213 : class I division 2 UL 508 |
|
product certifications |
CE
cULus RCM KC |
|
ambient air temperature for operation |
0...60 °C conforming to EN 61131-2
|
|
ambient air temperature for storage |
-20...60 °C
|
|
pollution degree |
2
|
|
relative humidity |
10...90 % (non-condensing)
|
|
operating altitude |
2000 m
|
|
vibration resistance |
3.5 mm constant amplitude (f = 5...9 Hz) conforming to EN/IEC
61131-2
9.8 m/s² (f = 9...150 Hz) conforming to EN/IEC 61131-2 |
|
shock resistance |
147 m/s² conforming to EN/IEC 61131-2
|
|
electromagnetic compatibility |
Electrostatic discharge immunity test, level 3 conforming to
EN/IEC 61000-4-2
|
