Schneider HMIPPF6A2701 Panel PC Performance - Flash Disk SSD - 12'' - AC - 2 Slots - Fanless
Overview
The Schneider HMIPPF6A2701 Panel PC is engineered for high-performance applications where reliability, durability, and compactness are paramount. This advanced 12-inch panel PC combines robust computing power with a sleek, fanless design, making it ideal for demanding industrial environments.
Key Features
High-Performance Flash Disk SSD: The HMIPPF6A2701 features an integrated Flash Disk SSD that ensures rapid data access and high-speed performance. With its solid-state storage, this panel PC delivers superior durability and reliability, minimizing the risk of mechanical failures and enhancing overall system responsiveness.
12-Inch High-Resolution Display: Equipped with a 12-inch TFT display, the HMIPPF6A2701 offers clear and vibrant visuals, ensuring optimal readability and user interaction. The screen's high resolution supports precise data monitoring and efficient control in various industrial applications.
Fanless Operation: Designed to operate without a fan, this panel PC maintains a silent and dust-resistant environment. The fanless architecture not only reduces the risk of mechanical failure but also contributes to a more reliable and maintenance-free operation, making it suitable for environments with high dust or particulate matter.
AC Power Supply: The panel PC operates on AC power, providing stable and continuous performance suitable for a range of industrial and commercial settings. This ensures reliable operation without the need for battery backups or frequent power source changes.
Dual Expansion Slots: The HMIPPF6A2701 is equipped with 2 expansion slots, allowing for customization and future upgrades. This flexibility supports various expansion cards and additional components, enabling you to tailor the panel PC to your specific application needs.
Durable and Robust Design: Built to withstand harsh conditions, the HMIPPF6A2701 features a rugged and industrial-grade design. Its sturdy construction ensures longevity and reliable performance even in demanding environments.
Applications
- Industrial Automation: Ideal for use in manufacturing and processing plants where durability and performance are crucial for controlling machinery and processes.
- Control Rooms: Perfect for control room applications where high visibility and reliability are essential for monitoring systems and data.
- Commercial Environments: Suitable for use in commercial settings requiring a compact, high-performance panel PC with a user-friendly interface.
Specifications
- Display Size: 12 inches
- Storage: Flash Disk SSD
- Power Supply: AC
- Expansion Slots: 2
- Cooling System: Fanless
Enhance your industrial or commercial operations with the Schneider HMIPPF6A2701 Panel PC, designed to provide unparalleled performance and reliability. Its advanced features and robust construction make it the perfect choice for demanding environments where efficiency and durability are key.
| range of product |
Magelis iPC
|
|
|---|---|---|
| product or component type |
PC panel
|
|
| processor name |
Intel i3 dual core 3rd generation 3217UE cache 3 MB
|
|
| chipset type |
Intel BD82QM77
|
|
| display size |
12 inch
|
|
| display colour |
16 million colours
|
|
| luminance |
375 cd/m²
|
|
| drive type |
DVD-RW
|
|
| video controller type |
Intel HD Graphics 4000
|
|
| operating system |
Windows 7 64 bits Ultimate multi-language
|
|
| software package |
Vijeo Designer run time demo
|
|
| bezel material |
Aluminium alloy
|
| terminal type |
Touchscreen display
|
|
|---|---|---|
| data storage equipment |
>= 60 GB Flash disk SSD MLC for 2000000 h
|
|
| display type |
Active matrix colour TFT LCD with LED backlight
|
|
| display resolution |
1024 x 768 pixels XGA
|
|
| backlight lifespan |
50000 hours at 25 °C
|
|
| view angle horizontal x vertical |
80 x 80°
|
|
| touch panel |
Analogue resistive
|
|
| memory type |
4 GB, expandable to 16 GB RAM DDR3
|
|
| type of cooling |
Fanless
|
|
| integrated connection type |
DVI video port bottom
Ethernet port with 2 RJ45 COM1 serial link male SUB-D 9 RS232C, transmission rate: 115 kbit/s bottom COM2 serial link male SUB-D 9 RS232C, transmission rate: 115 kbit/s bottom USB 2.0 type A, transmission rate: 480 Mbit/s front panel USB 3.0 type A with 4, transmission rate: 5 Gbit/s bottom Audio output mini-jack |
|
| port Ethernet |
10BASE-T/100BASE-T/1000BASE-T
|
|
| number of slots |
1 PCI 33 MHz
1 PCI express 2 Gbit/s |
|
| [Us] rated supply voltage |
100...240 V AC power supply
|
|
| network frequency |
45...65 Hz
|
|
| [In] rated current |
0.6...2 A
|
|
| inrush current |
20 A
|
|
| material |
Die cast aluminium
|
|
| display material |
Polyethylene sheet
|
|
| fixing mode |
By fixing kit with enclosure door (fasteners included)
|
|
| type of installation |
Indoor
|
|
| control type |
ON/OFF push-button (equipment ON and OFF)
Push-button (reset) |
|
| local signalling |
LED for link status
LED for RUN Multi-colour LED for power Orange LED for accessing Flash disk SSD (DISK) |
|
| function available |
RAID (Redundant Array of Independent Disks)
|
|
| width |
313 mm
|
|
| height |
239 mm
|
|
| depth |
135 mm
|
|
| cut-out dimensions |
301.5 (+ 1/- 0) x 227.5 (+ 1/- 0) x 1.6...9 mm
|
|
| product weight |
4.2 kg
|
|
| main type |
Performance
|
| IP degree of protection |
IP65 front panel conforming to EN/IEC 60529
|
|
|---|---|---|
| NEMA degree of protection |
NEMA 4X front panel
|
|
| product certifications |
CE
C-Tick GOST CULus 508 CULus CSA 22-2 No 142 CULus HazLoc Class I Division 2 UL 1604 CULus HazLoc Class I Division 2 ANSI/ISA 12-12-01 CULus HazLoc Class I Division 2 CSA 22-2 No 213 |
|
| pollution degree |
2 EN/IEC 61131-2
|
|
| electromagnetic compatibility |
Immunity to electromagnetic emissions class A EN 55022
Immunity to electromagnetic emissions class A EN 55011 Immunity to high frequency interference EN/IEC 61131-2 Immunity to high frequency interference EN/IEC 61000-4-x |
|
| ambient air temperature for operation |
0...50 °C vertical installation conforming to UL 508
0...45 °C vertical installation when using Gigabit Ethernet with HDD storage device conforming to UL 508 0...50 °C vertical installation conforming to IEC 61132-2 0...45 °C vertical installation when using Gigabit Ethernet with HDD storage device conforming to IEC 61132-2 |
|
| ambient air temperature for storage |
-20...60 °C conforming to IEC 60068-2-14 test Na
-20...60 °C conforming to IEC 60068-2-2 test Bb |
|
| relative humidity |
10...85 % non-condensing conforming to EN/IEC 60068-2-78
10...85 % non-condensing conforming to EN/IEC 60068-2-30 |
|
| operating altitude |
2000 m conforming to EN/IEC 61131-2
|
|
| vibration resistance |
1.75 mm 2...9 Hz continuous conforming to EN/IEC 60068-2-6 Fc
3.5 mm 2...9 Hz intermittently conforming to EN/IEC 60068-2-6 Fc 0.5 gn 9...200 Hz continuous conforming to EN/IEC 60068-2-6 Fc 1 gn 9...200 Hz intermittently conforming to EN/IEC 60068-2-6 Fc 1 mm 3...13.2 Hz continuous conforming to EN/IEC 60068-2-6 Fc 0.7 gn 13.2...100 Hz continuous conforming to EN/IEC 60068-2-6 Fc |
|
| shock resistance |
15 gn 11 ms conforming to IEC 60068-2-27, Ea tests
|
