Schneider HMIPSPC952D1W01 S-Panel PC Performance CF W19 DC WES - Advanced Industrial Computing Solution
Overview: The Schneider HMIPSPC952D1W01 S-Panel PC is a high-performance industrial panel PC designed for demanding applications in automation and control environments. Equipped with advanced features and robust specifications, this model ensures reliability, efficiency, and seamless integration into industrial systems.
Key Features:
High-Resolution Display: The S-Panel PC features a 19-inch widescreen display with a high resolution that delivers crisp, clear visuals and enhances user interaction with intuitive touch functionality. The display is designed for optimal readability in various lighting conditions, making it ideal for industrial settings.
Powerful Performance: Powered by a high-performance processor, the HMIPSPC952D1W01 ensures swift and efficient operation of complex applications. The panel PC is engineered to handle intensive computing tasks and real-time data processing, making it suitable for demanding industrial environments.
Durable Construction: Constructed with industrial-grade materials, the S-Panel PC is built to withstand harsh conditions including extreme temperatures, vibrations, and dust. Its rugged design ensures long-term reliability and minimal maintenance, even in challenging environments.
Versatile Connectivity: The panel PC offers a wide range of connectivity options, including multiple USB ports, Ethernet, and serial interfaces. This versatility supports seamless integration with various industrial devices and networks, enabling efficient communication and data exchange.
Enhanced User Interface: Featuring Windows Embedded Standard (WES), the HMIPSPC952D1W01 provides a user-friendly interface with customizable options. This operating system ensures compatibility with a broad range of industrial applications and facilitates easy software integration.
Energy Efficiency: Designed with energy efficiency in mind, the panel PC minimizes power consumption while maintaining high performance. This not only reduces operational costs but also supports environmentally sustainable practices.
Flexible Mounting Options: The S-Panel PC supports various mounting options, including panel, VESA, and wall mounts. This flexibility allows for easy installation in diverse industrial setups and configurations.
Applications: The Schneider HMIPSPC952D1W01 S-Panel PC is ideal for use in various industrial applications such as manufacturing automation, process control, machine visualization, and data acquisition. Its advanced features and robust design make it suitable for integration into control panels, HMI systems, and other industrial interfaces.
Specifications:
- Display Size: 19 inches
- Resolution: High resolution for enhanced clarity
- Processor: High-performance CPU
- Operating System: Windows Embedded Standard (WES)
- Connectivity: Multiple USB ports, Ethernet, serial interfaces
- Mounting Options: Panel, VESA, wall mounts
- Durability: Industrial-grade construction for harsh environments
- Energy Efficiency: Low power consumption
Why Choose Schneider HMIPSPC952D1W01? The Schneider HMIPSPC952D1W01 S-Panel PC represents a top-tier solution for industrial computing needs. Its combination of high performance, durability, and advanced features makes it an exceptional choice for applications requiring reliability and efficiency. With its versatile connectivity and user-friendly interface, this panel PC is designed to meet the demanding requirements of modern industrial operations.
Get in Touch: For more information about the Schneider HMIPSPC952D1W01 S-Panel PC or to request a quote, please contact us today. Our team of experts is ready to assist you with any inquiries and provide tailored solutions to meet your specific industrial needs.
range of product |
Magelis iPC
|
|
---|---|---|
product or component type |
Multi-touch screen
|
|
processor name |
Intel Core i3 4010U 1.7 GHz
|
|
chipset type |
Intel QM87
|
|
free slots |
1 Internal SATA HDD/SSD
1 CFast |
|
display size |
18.5 inch
|
|
display colour |
16777216 colors
|
|
luminance |
300 cd/m²
|
|
pixel resolution |
4096 x 4096
|
|
video controller type |
Intel HD Graphics 4400
|
|
software package |
EcoStruxture secure connect advisor annual subscription cyber
security license not included
EcoStruxure operator terminal expert run time HMI license not included EcoStruxure machine SCADA expert run time HMI/SCADA on configured offer only EcoStruxure augmented operator advisor server augmented operator license not included |
number of points |
5
|
|
---|---|---|
terminal type |
Touchscreen display
|
|
memory type |
RAM DDR3 8 GB internal
|
|
data storage equipment |
32 GB CFast card back side
|
|
aspect ratio |
16:9
|
|
display type |
LED
Colour TFT LCD |
|
display resolution |
1366 x 768 pixels WXGA
|
|
backlight lifespan |
50000 hours
|
|
view angle horizontal x vertical |
160 x 170°
|
|
touch panel |
Projected capacitive technology (PCT)
|
|
type of cooling |
Fanless
Passive |
|
watchdog timer |
1...255 ms
|
|
number of slots |
1 mini PCI Express full-size
|
|
[Us] rated supply voltage |
100...240 V AC with additional adaptor HMIYPSPMAC1
24 V DC +/- 20 % |
|
power consumption in W |
28...60 W
|
|
mechanical robustness |
7H hardness anti-scratch
|
|
function available |
Operate with water on screen
|
|
width |
488 mm
|
|
height |
309 mm
|
|
depth |
56.7 mm
|
|
cut-out dimensions |
479.3 (+/- 1) x 300.3 (+/- 0.7)
|
|
product weight |
7 kg
|
IP degree of protection |
IP66 front panel
|
|
---|---|---|
product certifications |
AS/NZS
CCC CE C-Tick EAC RCM |
|
standards |
CISPR 11
IEC 60950 IEC 61000-6-4 FCC part 15 class A IEC 61000-6-2 UL 60950 CSA C22.2 No 60950 |
|
directives |
2012/19/EU - WEEE directive
2006/95/EC - low voltage directive 1907/2006/EC - REACH directive 2011/65/EU - RoHS directive 2004/108/EC - electromagnetic compatibility |
|
pollution degree |
2
|
|
ambient air temperature for operation |
0...55 °C SSD
0...55 °C Cfast card 0...45 °C HDD |
|
ambient air temperature for storage |
-20...60 °C
|
|
relative humidity |
10...95 % non-condensing
|
|
operating altitude |
2000
|
|
vibration resistance |
1 gn 5...500 Hz HDD
|
