Schneider HMIPSPH752D1701 S-Panel PC Performance HDD W15 DC Windows 7
The Schneider HMIPSPH752D1701 S-Panel PC redefines performance and reliability in industrial computing. Engineered to meet the demanding requirements of industrial environments, this powerful Panel PC is designed to optimize operational efficiency and streamline processes.
Performance and Durability
Powered by a robust HDD W15 DC Windows 7 operating system, this Panel PC delivers exceptional performance, ensuring seamless operation in diverse industrial settings. Its high-performance capabilities facilitate swift data processing, enabling real-time monitoring, control, and analysis.
Rugged Design
Crafted with a focus on durability, the Schneider S-Panel PC withstands challenging environmental conditions. Its rugged design ensures resilience against shocks, vibrations, and fluctuations in temperature, making it an ideal solution for industrial automation and control systems.
Intuitive Interface
Featuring a user-friendly interface, this Panel PC enhances user experience and operational efficiency. The intuitive interface simplifies navigation, allowing for easy access to critical data and applications, empowering users to make informed decisions swiftly.
Key Features:
- HMIPSPH752D1701 Model: Specifically engineered for demanding industrial applications.
- Reliable HDD W15 DC Windows 7 OS: Ensures stability and seamless operation.
- Robust Build: Withstands harsh industrial environments.
- Enhanced Connectivity: Multiple ports for seamless integration with peripherals.
- High-Resolution Display: Provides clear and precise visualization of data.
Applications
The Schneider HMIPSPH752D1701 S-Panel PC is tailored for a wide range of industrial applications, including manufacturing, automation, process control, and more. Its versatility and reliability make it an invaluable asset in optimizing operational workflows.
SEO-Friendly Keywords
Ensure visibility and reach with optimized keywords:
- Schneider HMIPSPH752D1701
- S-Panel PC Performance HDD W15 DC Windows 7
- Industrial Panel PC
- Industrial Automation
- Control Systems
- Rugged Panel PC
- High-Performance Panel PC
Conclusion
Experience unmatched performance and reliability with the Schneider HMIPSPH752D1701 S-Panel PC. Built to excel in demanding industrial environments, this Panel PC sets the benchmark for efficiency, durability, and seamless operation.
| range of product |
Magelis iPC
|
|
|---|---|---|
| product or component type |
Multi-touch screen
|
|
| processor name |
Intel Core i3 4010U 1.7 GHz
|
|
| chipset type |
Intel QM87
|
|
| free slots |
1 Internal SATA HDD/SSD
1 CFast |
|
| display size |
15.6 inch
|
|
| display colour |
16777216 colors
|
|
| luminance |
300 cd/m²
|
|
| pixel resolution |
4096 x 4096
|
|
| video controller type |
Intel HD Graphics 4400
|
|
| operating system |
Windows 7 64 bits Ultimate SP1
|
|
| software package |
EcoStruxture secure connect advisor annual subscription cyber
security license not included
EcoStruxure operator terminal expert run time HMI license not included EcoStruxure machine SCADA expert run time HMI/SCADA on configured offer only EcoStruxure augmented operator advisor server augmented operator license not included |
| number of points |
5
|
|
|---|---|---|
| terminal type |
Touchscreen display
|
|
| memory type |
RAM DDR3 8 GB internal
|
|
| data storage equipment |
500 GB enterprise hard disk back side
|
|
| aspect ratio |
16:9
|
|
| display type |
LED
Colour TFT LCD |
|
| display resolution |
1366 x 768 pixels WXGA
|
|
| backlight lifespan |
50000 hours
|
|
| view angle horizontal x vertical |
150 x 140°
|
|
| touch panel |
Projected capacitive technology (PCT)
|
|
| type of cooling |
Fanless
Passive |
|
| watchdog timer |
1...255 ms
|
|
| number of slots |
1 mini PCI Express full-size
|
|
| [Us] rated supply voltage |
100...240 V AC with additional adaptor HMIYPSPMAC1
24 V DC +/- 20 % |
|
| power consumption in W |
18...60 W
|
|
| mechanical robustness |
7H hardness anti-scratch
|
|
| local signalling |
Buzzer
Green LED for on Orange LED for stand-by |
|
| function available |
Operate with water on screen
|
|
| width |
419.7 mm
|
|
| height |
269 mm
|
|
| depth |
56.7 mm
|
|
| cut-out dimensions |
412.4 (+/- 0.7) x 261.7 (+/- 0.4)
|
|
| product weight |
6 kg
|
| IP degree of protection |
IP66 front panel
|
|
|---|---|---|
| product certifications |
CCC
RCM AS/NZS CE EAC C-Tick |
|
| standards |
FCC part 15 class A
UL 60950 IEC 61000-6-2 CISPR 11 CSA C22.2 No 60950 IEC 61000-6-4 IEC 60950 |
|
| directives |
2011/65/EU - RoHS directive
2004/108/EC - electromagnetic compatibility 2012/19/EU - WEEE directive 2006/95/EC - low voltage directive 1907/2006/EC - REACH directive |
|
| pollution degree |
2
|
|
| ambient air temperature for operation |
0...55 °C SSD
0...55 °C Cfast card 0...45 °C HDD 0...45 °C Mini PCIe |
|
| ambient air temperature for storage |
-20...60 °C
|
|
| relative humidity |
10...95 % non-condensing
|
|
| operating altitude |
2000
|
|
| vibration resistance |
1 gn 5...500 Hz HDD
2 gn 5...500 Hz SSD 2 gn 5...500 Hz Cfast card |
Schneider HMIPSPH752D1701 S-Panel PC Performance HDD W15 DC Windows 7
- Brand: Schneider
- Product Code: HMIPSPH752D1701
- Availability: 1000
Tags: Schneider HMIPSPH752D1701, S-Panel PC, Performance HDD, W15 DC Windows 7, Industrial Automation, Control Systems, Rugged Panel PC
