Schneider HMIPSPS752D180L S-Panel PC – Performance SSD, 15" Display, DC, Windows 7
Overview
The Schneider HMIPSPS752D180L S-Panel PC is a high-performance, rugged computing solution designed for demanding industrial environments. Featuring a 15" display and a solid-state drive (SSD) for enhanced reliability and speed, this panel PC is engineered to deliver exceptional performance and durability. Ideal for use in automation, manufacturing, and process control applications, it operates seamlessly with Windows 7, providing a robust platform for various industrial applications.
Key Features
15" High-Resolution Display: The Schneider HMIPSPS752D180L is equipped with a 15" TFT display, offering clear and vibrant visuals with a high resolution that ensures precise data representation and ease of use in a wide range of lighting conditions.
Performance SSD: The integrated SSD provides superior data access speeds, enhancing overall system performance and reliability. This solid-state storage solution ensures quick boot times and fast data retrieval, crucial for real-time processing and operations.
Durable and Reliable Design: Designed to withstand harsh industrial environments, the HMIPSPS752D180L features a rugged construction that offers resistance to dust, moisture, and vibration, ensuring reliable operation even in challenging conditions.
Windows 7 Operating System: Pre-installed with Windows 7, this panel PC provides a stable and familiar operating environment. It supports a wide range of industrial software applications and facilitates smooth integration with existing systems.
DC Power Supply: The panel PC is powered by a direct current (DC) supply, offering flexibility in power management and ensuring compatibility with various industrial power sources.
Industrial-Grade Performance: The Schneider HMIPSPS752D180L is engineered for high performance, making it suitable for demanding applications such as machine control, data acquisition, and process monitoring.
Enhanced Connectivity: The device includes multiple communication interfaces to ensure seamless integration with other industrial equipment and systems.
Applications
The Schneider HMIPSPS752D180L S-Panel PC is ideal for use in:
- Manufacturing and Automation: Control and monitor industrial processes with ease.
- Process Control: Manage and optimize production lines and equipment.
- Data Acquisition: Collect and analyze data from various sources efficiently.
Specifications
- Display Size: 15 inches
- Display Type: TFT
- Storage: SSD
- Operating System: Windows 7
- Power Supply: DC
- Durability: Industrial-grade construction
- Connectivity: Multiple interfaces
Why Choose Schneider HMIPSPS752D180L?
Choose the Schneider HMIPSPS752D180L S-Panel PC for its unparalleled performance, rugged durability, and user-friendly interface. Whether you need reliable computing in harsh environments or a robust solution for critical applications, this panel PC delivers the power and resilience you need to keep your operations running smoothly.
For more information or to request a quote, contact us today!
| range of product |
Magelis iPC
|
|
|---|---|---|
| product or component type |
Multi-touch screen
|
|
| processor name |
Intel Core i3 4010U 1.7 GHz
|
|
| chipset type |
Intel QM87
|
|
| free slots |
1 Internal SATA HDD/SSD
1 CFast |
|
| display size |
15.6 inch
|
|
| display colour |
16777216 colors
|
|
| luminance |
300 cd/m²
|
|
| pixel resolution |
4096 x 4096
|
|
| video controller type |
Intel HD Graphics 4400
|
|
| operating system |
Windows 7 64 bits Ultimate SP1 multi-language
|
|
| software package |
EcoStruxture secure connect advisor annual subscription cyber
security license not included
EcoStruxure operator terminal expert run time HMI license not included EcoStruxure machine SCADA expert run time HMI/SCADA on configured offer only EcoStruxure augmented operator advisor server augmented operator license not included Vijeo Citect DVD SCADA license not included |
| number of points |
5
|
|
|---|---|---|
| terminal type |
Touchscreen display
|
|
| memory type |
RAM DDR3 8 GB internal
|
|
| data storage equipment |
256 GB SSD back side for 1500000 h
|
|
| aspect ratio |
16:9
|
|
| display type |
LED
Colour TFT LCD |
|
| display resolution |
1366 x 768 pixels WXGA
|
|
| backlight lifespan |
50000 hours
|
|
| view angle horizontal x vertical |
150 x 140°
|
|
| touch panel |
Projected capacitive technology (PCT)
|
|
| type of cooling |
Fanless
Passive |
|
| watchdog timer |
1...255 ms
|
|
| electrical connection |
Connector SMA for 3 ways
|
|
| number of slots |
1 mini PCI Express full-size
|
|
| [Us] rated supply voltage |
100...240 V AC with additional adaptor HMIYPSPMAC1
24 V DC +/- 20 % |
|
| power consumption in W |
18...60 W
|
|
| mechanical robustness |
7H hardness anti-scratch
|
|
| local signalling |
Buzzer
Green LED for on Orange LED for stand-by |
|
| function available |
Operate with water on screen
|
|
| width |
419.7 mm
|
|
| height |
269 mm
|
|
| depth |
56.7 mm
|
|
| cut-out dimensions |
412.4 (+/- 0.7) x 261.7 (+/- 0.4)
|
|
| product weight |
6 kg
|
| IP degree of protection |
IP66 front panel
|
|
|---|---|---|
| product certifications |
AS/NZS
EAC C-Tick RCM CCC CE |
|
| standards |
CSA C22.2 No 60950
IEC 61000-6-4 CISPR 11 FCC part 15 class A IEC 60950 UL 60950 IEC 61000-6-2 |
|
| directives |
1907/2006/EC - REACH directive
2011/65/EU - RoHS directive 2012/19/EU - WEEE directive 2006/95/EC - low voltage directive 2004/108/EC - electromagnetic compatibility |
|
| pollution degree |
2
|
|
| ambient air temperature for operation |
0...55 °C SSD
0...55 °C Cfast card 0...45 °C HDD 0...45 °C Mini PCIe |
|
| ambient air temperature for storage |
-20...60 °C
|
|
| relative humidity |
10...95 % non-condensing
|
|
| operating altitude |
2000
|
|
| vibration resistance |
1 gn 5...500 Hz HDD
2 gn 5...500 Hz SSD 2 gn 5...500 Hz Cfast card |
