Schneider HMISCU6B5 3.5" Color Touch Controller Panel - Dig 8 Inputs/8 Outputs + Ana 4 In/2 Out
Experience seamless control and unparalleled functionality with the Schneider HMISCU6B5, a cutting-edge 3.5" color touch controller panel designed to elevate industrial automation to new heights. This robust, user-friendly interface is equipped with a suite of features, ensuring precise management and monitoring of your systems.
Key Features:
Vivid Touch Display: The 3.5" color touch screen provides a vibrant and intuitive interface, enabling swift navigation and easy access to critical information.
Extensive Input/Output Capacity: With 8 digital inputs and 8 digital outputs, this controller panel empowers comprehensive connectivity, facilitating seamless integration with a multitude of devices and systems. Additionally, its 4 analog inputs and 2 analog outputs provide versatile control over analog signals.
Enhanced Control and Monitoring: Benefit from enhanced control capabilities and real-time monitoring, allowing for precise adjustments and quick response to system changes.
Robust Build Quality: Crafted with durability in mind, the Schneider HMISCU6B5 ensures reliable performance in diverse industrial environments, withstanding demanding conditions effortlessly.
Seamless Compatibility: Compatible with various industrial systems and machinery, offering seamless integration and compatibility with Schneider's range of products.
Intelligent Functionality: Empowered by advanced technology, this controller panel boasts intelligent functionalities, streamlining operations and optimizing efficiency.
User-Friendly Interface: Designed with user convenience at its core, the interface offers a user-friendly experience, simplifying complex operations and reducing training time.
Applications:
- Manufacturing Automation
- Process Control
- Equipment Monitoring
- Industrial IoT Integration
SEO-Friendly Keywords:
Schneider HMISCU6B5, 3.5" Color Touch Controller Panel, Industrial Automation, Digital Inputs/Outputs, Analog Inputs/Outputs, Industrial Control Panel, Schneider Electric, Industrial IoT, Process Monitoring, Equipment Control.
Elevate your industrial control and monitoring capabilities with the Schneider HMISCU6B5 3.5" color touch controller panel. Empower your systems with precision, reliability, and seamless connectivity. Invest in Schneider's cutting-edge technology for enhanced efficiency and control.
| range of product |
Magelis SCU
|
|
|---|---|---|
| product or component type |
Small touch HMI controller
|
|
| display size |
3.5 inch
|
|
| display type |
With backlit LED colour TFT LCD
|
|
| touch panel |
Analogue
|
|
| device presentation |
Complete product
|
| display resolution |
320 x 240 pixels QVGA
|
|
|---|---|---|
| backlight lifespan |
50000 hours with 65000 colours
|
|
| brightness |
16 levels via touch panel
|
|
| view angle horiz x vert |
60° left
60° right 40° top 60° bottom |
|
| character font |
ASCII
Chinese (simplified Chinese) Japanese (ANK, Kanji) Korean Taiwanese (traditional Chinese) |
|
| supply |
External source
|
|
| [Us] rated supply voltage |
24 V at 20.4...28.8 V DC
|
|
| immunity to microbreaks |
<= 10 ms
|
|
| inrush current |
<= 30 A
|
|
| power consumption in W |
15 W
|
|
| local signalling |
No indicator
|
|
| number of pages |
Limited by internal memory capacity
|
|
| software designation |
SoMachine
|
|
| operating system |
Magelis
|
|
| processor name |
CPU RISC
|
|
| processor frequency |
333 MHz
|
|
| memory description |
128 MB flash memory, type: NAND
128 kB internal data storage memory, type: FRAM 128 MB application run memory, type: DRAM |
|
| integrated connection type |
1 RJ45 connector serial link with RS232/RS485 interface at <=
115.2 kbits/s
1 RJ45 connector Ethernet TCP/IP 1 USB 2.0 type mini B 1 USB 2.0 type A SUB-D 9 connector CANopen master bus |
|
| realtime clock |
Built-in
|
|
| downloadable protocols |
Modbus
Modbus TCP/IP CANopen |
|
| fixing mode |
By 1 nut - diameter: Ø 22 mm, mounting on: 1...6 mm thick panel
|
|
| enclosure material |
PC/PBT
|
|
| shock resistance |
147 m/s² (duration=11 ms) conforming to IEC 60068-2-27 on DIN
rail
294 m/s² (duration=6 ms) conforming to IEC 60068-2-27 on panel mounting |
|
| vibration resistance |
+/- 3.5 mm (f=5...9 Hz) conforming to IEC 60068-2-6
1 gn (f=9...150 Hz) conforming to IEC 60068-2-6 |
|
| electromagnetic compatibility |
Electrostatic discharge immunity test - test level: 8 kV, air
discharge conforming to IEC 61000-4-2
Electrostatic discharge immunity test - test level: 6 kV, contact discharge conforming to IEC 61000-4-2 Susceptibility to electromagnetic fields - test level: 10 V/m, 80 MHz...3 GHz conforming to IEC 61000-4-3 Electrical fast transient/burst immunity test - test level: 2 kV, power lines conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, between analogue I/O and operating voltage conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 2 kV, relay wires conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, Ethernet line conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, COM line conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, CAN line conforming to IEC 61000-4-4 Surge immunity test - test level: 2 kV, power supply (common mode) conforming to IEC 61000-4-5 Surge immunity test - test level: 1 kV, power supply (differential mode) conforming to IEC 61000-4-5 Surge immunity test - test level: 1 kV common mode, digital I/O conforming to IEC 61000-4-5 Surge immunity test - test level: 0.5 kV differential mode, digital I/O conforming to IEC 61000-4-5 Conducted RF disturbances - test level: 10 V, 0.15...80 MHz conforming to IEC 61000-4-6 Conducted emission - test level: 150 kHz...30 MHz conforming to EN 55011 Radiated emission - test level: 30 MHz...1 GHz conforming to EN 55011 |
|
| discrete input number |
2 for fast input (normal mode) conforming to IEC 61131-2 Type 1
6 for digital input conforming to IEC 61131-2 Type 1 |
|
| discrete input voltage |
24 V DC discrete input logic:sink or source (positive/negative)
|
|
| number of common point |
1 for fast input (HSC mode)
1 for digital input |
|
| discrete input current |
7.83 mA for fast input
5 mA for digital |
|
| input impedance |
4.7 kOhm
2.81 kOhm |
|
| sensor power supply |
15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1):
>= 5 mA, voltage (state 0): <= 5 V, current (state 0): <= 1.5 mA
15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1): >= 2.5 mA, voltage (state 0): <= 5 V, current (state 0): <= 1 mA |
|
| configurable filtering time |
0 ms no filter (none)
0.004...0.04 ms bounce filter (latch/event and cumulative filter by step Nx0.5ms (64>=N>=2)) 3...12 ms integrator (none/run/stop) |
|
| input frequency |
100 kHz for fast input (encoder mode) - control type A/B
100 kHz for fast input - control type single phase 100 kHz for fast input - control type pulse/direction |
|
| cable distance between devices |
Shielded cable: 10 m for fast input
Shielded cable: 100 m for digital input Unshielded cable: 50 m for digital input |
|
| connection pitch |
3.5 mm
|
|
| overvoltage protection |
With
|
|
| isolation between channels and internal logic |
500 V DC
|
|
| isolation between channels |
None
|
|
| discrete output number |
2 fast output (normal mode), output logic: source
6 digital output, output logic: source |
|
| discrete output voltage |
24 V DC (voltage limit: 19.2...28.8 V) with transistor discrete
output(s)
24 V DC (voltage limit: 5...30 V) with relay discrete output(s) 220 V AC (voltage limit: 100...250 V) with relay discrete output(s) |
|
| input/output number |
2 for fast input, terminal(s): FI0...FI1
2 for fast output, terminal(s): FQ0...FQ1 6 for digital input, terminal(s): DI0...DI5 6 for digital output, terminal(s): DQ0...DQ5 |
|
| discrete output current |
300 mA, response time 2 ms for fast output (normal mode)
50 mA, response time 2 ms for fast output (PWM or PTO mode) 2 A (current per output common:4 A), response time 5 ms with opening contact for digital output 2 A (current per output common:4 A), response time 2 ms with closing contact for digital output |
|
| insulation resistance |
> 10 MOhm between the I/O and internal logic
> 10 MOhm between power supply and earth |
|
| output frequency |
<= 100 kHz for fast output (PTO mode)
<= 1 kHz for fast output (PWM mode) |
|
| absolute accuracy error |
+/- 0.1 % of full scale of cyclic ratio 1...99% for fast output
(PWM or PTO mode)
1 % of full scale of cyclic ratio 1...99% for fast output (PWM or PTO mode) +/- 5 % of full scale of cyclic ratio 10...90% for fast output (PWM or PTO mode) +/- 10 % of full scale of cyclic ratio 20...80% for fast output (PWM or PTO mode) +/- 15 % of full scale of cyclic ratio 30...70% for fast output (PWM or PTO mode) |
|
| analogue input number |
2 for analog input
2 for RTDs |
|
| analogue input range |
0...20 mA/4...20 mA - resolution: 12 bits, input impedance: 250
Ohm (tolerance: +/- 1 %)
-10...+10 V or 0...10 V - resolution: 12 bits + sign, input impedance: >= 1 MOhm |
|
| analogue input type |
RTD at - 200...600 °C - resolution: 16 bits temperature probe:
Pt 100/Pt 1000
RTD at - 50...200 °C - resolution: 16 bits temperature probe: Ni 100/Ni 1000 RTD at - 200...760 °C - resolution: 16 bits (thermocouple J) RTD at - 240...1370 °C - resolution: 16 bits (thermocouple K) RTD at 0...1600 °C - resolution: 16 bits (thermocouple R) RTD at 200...1800 °C - resolution: 16 bits (thermocouple B) RTD at 0...1600 °C - resolution: 16 bits (thermocouple S) RTD at - 200...400 °C - resolution: 16 bits (thermocouple T) RTD at - 200...900 °C - resolution: 16 bits (thermocouple E) RTD at - 200...1300 °C - resolution: 16 bits (thermocouple N) |
|
| analogue output number |
2 resistive load for 12 bits + sign
|
|
| analogue output range |
0...20 mA/4...20 mA (> 300 Ohm) for open-circuit
-10...10 V/0...10 V (> 2 kOhm) for short-circuit |
|
| height |
74.95 mm
|
|
| width |
128 mm
|
|
| depth |
102 mm
|
|
| product weight |
0.551 kg
|
| standards |
EN 61131-2
FCC Class A IEC 61000-6-2 RoHS compliant UL 508 ANSI/ISA 12-12-01 WEEE directive 2002/96/EC CSA C22.2 No 213 Class I Division 2 RoHS China SJ/T 11363-2006 |
|
|---|---|---|
| product certifications |
C-Tick
CULus 508 GOST CUL 1604 Class 1 Division 2 KCC CULus CSA 22-2 No 142 |
|
| marking |
CE
|
|
| ambient air temperature for operation |
0...50 °C
|
|
| ambient air temperature for storage |
-20...60 °C
|
|
| relative humidity |
5...85 % without condensation
|
|
| operating altitude |
<= 2000 m
|
|
| storage altitude |
0...10000 m
|
|
| maximum pressure |
800...1114 hPa
|
|
| IP degree of protection |
IP65 for front panel conforming to IEC 60529
IP20 for rear panel conforming to IEC 60529 |
|
| NEMA degree of protection |
NEMA 4X for front panel
|
|
| pollution degree |
2 conforming to IEC 60664
|
|
| environmental characteristic |
Corrosive gas free
|
Schneider HMISCU6B5 3.5" Color Touch Controller Panel - Digital 8 Inputs/8 Outputs + Analog 4 In/2 Out
- Brand: Schneider
- Product Code: HMISCU6B5
- Availability: 1000
Tags: Schneider, HMISCU6B5, 3.5" touch panel, color controller, digital inputs, digital outputs, analog inputs, analog outputs, industrial automation
