Schneider HMISCU8B5 5.7” Color Touch Controller Panel
Optimize Your Automation with Precision Control
Elevate your automation and control capabilities with the Schneider HMISCU8B5 5.7” Color Touch Controller Panel. This state-of-the-art device combines intuitive touch-screen functionality with robust I/O capabilities, ensuring seamless integration and superior performance in industrial environments.
Key Features:
5.7-Inch Color Touch Screen: The HMISCU8B5 features a high-resolution 5.7” TFT color display, offering crisp and clear visual feedback. Its user-friendly touch interface facilitates easy navigation and control, enhancing operational efficiency.
Versatile I/O Configuration:
- Digital Inputs (8): Accurately monitor and respond to a range of digital signals with eight configurable digital inputs.
- Digital Outputs (8): Manage and control external devices with eight versatile digital outputs.
- Analog Inputs (4): Gather precise data from analog sources with four analog inputs, perfect for sensors and measurement devices.
- Analog Outputs (2): Deliver accurate analog signals to external systems with two high-resolution analog outputs.
Enhanced Connectivity: The HMISCU8B5 supports a variety of communication protocols, ensuring seamless integration with other automation equipment and systems. Its connectivity options are designed to meet the demands of modern industrial automation.
Robust Design: Engineered for durability, the HMISCU8B5 is built to withstand the rigors of industrial environments. Its rugged construction ensures reliable performance even in challenging conditions.
Intuitive Programming: With Schneider’s advanced software tools, programming and configuration are straightforward. Customize the touch panel’s functionality to meet specific application needs, optimizing performance and user experience.
Compact and Efficient: The compact design of the HMISCU8B5 makes it an ideal choice for applications where space is limited. Despite its small footprint, it delivers powerful performance and flexibility.
Applications:
The Schneider HMISCU8B5 is suitable for a wide range of industrial applications, including:
- Manufacturing automation
- Process control
- Building management systems
- Machine control and monitoring
Technical Specifications:
- Display Size: 5.7 inches
- Display Type: TFT Color
- Digital Inputs: 8
- Digital Outputs: 8
- Analog Inputs: 4
- Analog Outputs: 2
Why Choose Schneider HMISCU8B5?
The Schneider HMISCU8B5 5.7” Color Touch Controller Panel offers a perfect balance of functionality, durability, and ease of use. Its advanced features and robust design make it an excellent choice for industrial control and automation, ensuring reliable performance and enhanced operational efficiency.
| range of product |
Magelis SCU
|
|
|---|---|---|
| product or component type |
Small touch HMI controller
|
|
| display size |
5.7 inch
|
|
| display type |
With backlit LED colour TFT LCD
|
|
| touch panel |
Analogue
|
|
| device presentation |
Complete product
|
| display resolution |
320 x 240 pixels QVGA
|
|
|---|---|---|
| backlight lifespan |
50000 hours with 65000 colours
|
|
| brightness |
16 levels via touch panel
|
|
| view angle horiz x vert |
60° left
60° right 40° top 60° bottom |
|
| character font |
ASCII
Chinese (simplified Chinese) Japanese (ANK, Kanji) Korean Taiwanese (traditional Chinese) |
|
| supply |
External source
|
|
| [Us] rated supply voltage |
24 V at 20.4...28.8 V DC
|
|
| immunity to microbreaks |
<= 10 ms
|
|
| inrush current |
<= 30 A
|
|
| power consumption in W |
24 W
|
|
| local signalling |
No indicator
|
|
| number of pages |
Limited by internal memory capacity
|
|
| software designation |
SoMachine
|
|
| operating system |
Magelis
|
|
| processor name |
CPU RISC
|
|
| processor frequency |
333 MHz
|
|
| memory description |
128 MB flash memory, type: NAND
128 kB internal data storage memory, type: FRAM 128 MB application run memory, type: DRAM |
|
| integrated connection type |
1 RJ45 connector serial link with RS232/RS485 interface at <=
115.2 kbits/s
1 RJ45 connector Ethernet TCP/IP 1 USB 2.0 type mini B 1 USB 2.0 type A SUB-D 9 connector CANopen master bus |
|
| realtime clock |
Built-in
|
|
| downloadable protocols |
Modbus
Modbus TCP/IP CANopen |
|
| fixing mode |
By 1 nut - diameter: Ø 22 mm, mounting on: 1...6 mm thick panel
|
|
| enclosure material |
PC/PBT and PAA
|
|
| shock resistance |
147 m/s² (duration=11 ms) conforming to IEC 60068-2-27 on DIN
rail
294 m/s² (duration=6 ms) conforming to IEC 60068-2-27 on panel mounting |
|
| vibration resistance |
+/- 3.5 mm (f=5...9 Hz) conforming to IEC 60068-2-6
1 gn (f=9...150 Hz) conforming to IEC 60068-2-6 |
|
| electromagnetic compatibility |
Electrostatic discharge immunity test - test level: 8 kV, air
discharge conforming to IEC 61000-4-2
Electrostatic discharge immunity test - test level: 6 kV, contact discharge conforming to IEC 61000-4-2 Susceptibility to electromagnetic fields - test level: 10 V/m, 80 MHz...3 GHz conforming to IEC 61000-4-3 Electrical fast transient/burst immunity test - test level: 2 kV, power lines conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, between analogue I/O and operating voltage conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 2 kV, relay wires conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, Ethernet line conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, COM line conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test - test level: 1 kV, CAN line conforming to IEC 61000-4-4 Surge immunity test - test level: 2 kV, power supply (common mode) conforming to IEC 61000-4-5 Surge immunity test - test level: 1 kV, power supply (differential mode) conforming to IEC 61000-4-5 Surge immunity test - test level: 1 kV common mode, digital I/O conforming to IEC 61000-4-5 Surge immunity test - test level: 0.5 kV differential mode, digital I/O conforming to IEC 61000-4-5 Conducted RF disturbances - test level: 10 V, 0.15...80 MHz conforming to IEC 61000-4-6 Conducted emission - test level: 150 kHz...30 MHz conforming to EN 55011 Radiated emission - test level: 30 MHz...1 GHz conforming to EN 55011 |
|
| discrete input number |
2 for fast input (normal mode) conforming to IEC 61131-2 Type 1
6 for digital input conforming to IEC 61131-2 Type 1 |
|
| discrete input voltage |
24 V DC discrete input logic:sink or source (positive/negative)
|
|
| number of common point |
1 for fast input (HSC mode)
1 for digital input |
|
| discrete input current |
7.83 mA for fast input
5 mA for digital |
|
| input impedance |
4.7 kOhm
2.81 kOhm |
|
| sensor power supply |
15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1):
>= 5 mA, voltage (state 0): <= 5 V, current (state 0): <= 1.5 mA
15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1): >= 2.5 mA, voltage (state 0): <= 5 V, current (state 0): <= 1 mA |
|
| configurable filtering time |
0 ms no filter (none)
0.004...0.04 ms bounce filter (latch/event and cumulative filter by step Nx0.5ms (64>=N>=2)) 3...12 ms integrator (none/run/stop) |
|
| input frequency |
100 kHz for fast input (encoder mode) - control type A/B
100 kHz for fast input - control type single phase 100 kHz for fast input - control type pulse/direction |
|
| cable distance between devices |
Shielded cable: 10 m for fast input
Shielded cable: 100 m for digital input Unshielded cable: 50 m for digital input |
|
| connection pitch |
3.5 mm
|
|
| overvoltage protection |
With
|
|
| isolation between channels and internal logic |
500 V DC
|
|
| isolation between channels |
None
|
|
| discrete output number |
2 fast output (normal mode), output logic: source
6 digital output, output logic: source |
|
| discrete output voltage |
24 V DC (voltage limit: 19.2...28.8 V) with transistor discrete
output(s)
24 V DC (voltage limit: 5...30 V) with relay discrete output(s) 220 V AC (voltage limit: 100...250 V) with relay discrete output(s) |
|
| input/output number |
2 for fast input, terminal(s): FI0...FI1
2 for fast output, terminal(s): FQ0...FQ1 6 for digital input, terminal(s): DI0...DI5 6 for digital output, terminal(s): DQ0...DQ5 |
|
| discrete output current |
300 mA, response time 2 ms for fast output (normal mode)
50 mA, response time 2 ms for fast output (PWM or PTO mode) 2 A (current per output common:4 A), response time 5 ms with opening contact for digital output 2 A (current per output common:4 A), response time 2 ms with closing contact for digital output |
|
| insulation resistance |
> 10 MOhm between the I/O and internal logic
> 10 MOhm between power supply and earth |
|
| output frequency |
<= 100 kHz for fast output (PTO mode)
<= 1 kHz for fast output (PWM mode) |
|
| absolute accuracy error |
+/- 0.1 % of full scale of cyclic ratio 1...99% for fast output
(PWM or PTO mode)
1 % of full scale of cyclic ratio 1...99% for fast output (PWM or PTO mode) +/- 5 % of full scale of cyclic ratio 10...90% for fast output (PWM or PTO mode) +/- 10 % of full scale of cyclic ratio 20...80% for fast output (PWM or PTO mode) +/- 15 % of full scale of cyclic ratio 30...70% for fast output (PWM or PTO mode) |
|
| analogue input number |
2 for analog input
2 for RTDs |
|
| analogue input range |
0...20 mA/4...20 mA - resolution: 12 bits, input impedance: 250
Ohm (tolerance: +/- 1 %)
-10...+10 V or 0...10 V - resolution: 12 bits + sign, input impedance: >= 1 MOhm |
|
| analogue input type |
RTD at - 200...600 °C - resolution: 16 bits temperature probe:
Pt 100/Pt 1000
RTD at - 50...200 °C - resolution: 16 bits temperature probe: Ni 100/Ni 1000 RTD at - 200...760 °C - resolution: 16 bits (thermocouple J) RTD at - 240...1370 °C - resolution: 16 bits (thermocouple K) RTD at 0...1600 °C - resolution: 16 bits (thermocouple R) RTD at 200...1800 °C - resolution: 16 bits (thermocouple B) RTD at 0...1600 °C - resolution: 16 bits (thermocouple S) RTD at - 200...400 °C - resolution: 16 bits (thermocouple T) RTD at - 200...900 °C - resolution: 16 bits (thermocouple E) RTD at - 200...1300 °C - resolution: 16 bits (thermocouple N) |
|
| analogue output number |
2 resistive load for 12 bits + sign
|
|
| analogue output range |
0...20 mA/4...20 mA (> 300 Ohm) for open-circuit
-10...10 V/0...10 V (> 2 kOhm) for short-circuit |
|
| height |
129.4 mm
|
|
| width |
163 mm
|
|
| depth |
76.22 mm
|
|
| product weight |
0.803 kg
|
| standards |
EN 61131-2
FCC Class A IEC 61000-6-2 RoHS compliant UL 508 ANSI/ISA 12-12-01 WEEE directive 2002/96/EC CSA C22.2 No 213 Class I Division 2 RoHS China SJ/T 11363-2006 |
|
|---|---|---|
| product certifications |
C-Tick
CULus 508 GOST CUL 1604 Class 1 Division 2 KCC CULus CSA 22-2 No 142 |
|
| marking |
CE
|
|
| ambient air temperature for operation |
0...50 °C
|
|
| ambient air temperature for storage |
-20...60 °C
|
|
| relative humidity |
5...85 % without condensation
|
|
| operating altitude |
<= 2000 m
|
|
| storage altitude |
0...10000 m
|
|
| maximum pressure |
800...1114 hPa
|
|
| IP degree of protection |
IP65 for front panel conforming to IEC 60529
IP20 for rear panel conforming to IEC 60529 |
|
| NEMA degree of protection |
NEMA 4X for front panel
|
|
| pollution degree |
2 conforming to IEC 60664
|
|
| environmental characteristic |
Corrosive gas free
|
Schneider HMISCU8B5 5.7” Color Touch Controller Panel - Digital 8 Inputs/8 Outputs + Analog 4 In/2 Out
