Schneider HMISTO705 4.3" Wide Screen Touch Panel with RS-232 Terminal Block
Elevate your industrial automation and control capabilities with the Schneider HMISTO705 4.3" Wide Screen Touch Panel. This high-performance touch panel is engineered to provide exceptional user experience, robust functionality, and seamless integration for a variety of industrial applications.
Key Features:
High-Resolution Display: The HMISTO705 features a 4.3-inch widescreen display with a resolution of 480 x 272 pixels. This high-resolution touch screen offers clear, crisp visuals and enables intuitive interaction with your control systems, enhancing operational efficiency.
RS-232 Terminal Block: Equipped with an RS-232 terminal block, this touch panel facilitates reliable serial communication with external devices. This feature is crucial for integrating the panel with legacy systems or other serial communication peripherals, ensuring versatile connectivity options.
Advanced Touch Technology: The HMISTO705 incorporates advanced capacitive touch technology, providing a responsive and durable interface. The touch screen is designed to withstand rigorous industrial environments while maintaining accuracy and ease of use.
Robust Build Quality: Constructed with a durable and rugged housing, the HMISTO705 is built to withstand the demands of industrial environments. Its resistance to dust, moisture, and extreme temperatures makes it suitable for a wide range of applications.
User-Friendly Interface: Schneider's intuitive design ensures that operators can quickly and easily navigate through the user interface. Customizable screens and graphical elements allow for tailored control and monitoring solutions to meet specific operational needs.
Versatile Application: Ideal for use in manufacturing, process control, and automation systems, the HMISTO705 is versatile and adaptable. It supports various protocols and can be seamlessly integrated into existing systems to enhance functionality and control.
Efficient Connectivity: The inclusion of the RS-232 terminal block allows for straightforward connection to other devices, enabling efficient data transfer and system integration. This feature supports the seamless exchange of information between the touch panel and connected equipment.
Specifications:
- Display Size: 4.3 inches
- Resolution: 480 x 272 pixels
- Touch Technology: Capacitive
- Communication Ports: RS-232 Terminal Block
- Operating Temperature Range: [Specify range if available]
- Enclosure Rating: [Specify rating if available]
- Dimensions: [Specify dimensions]
- Weight: [Specify weight]
Applications:
The Schneider HMISTO705 is ideal for a variety of industrial and commercial applications, including:
- Manufacturing Control Panels
- Process Automation Systems
- Building Management Systems
- Machine Interfaces
- Energy Management Systems
Benefits:
- Enhanced operator interaction with high-resolution touch screen.
- Reliable and flexible connectivity through RS-232 terminal block.
- Durable construction for demanding environments.
- User-friendly interface for improved control and monitoring.
- Versatile integration capabilities with existing systems.
Why Choose Schneider HMISTO705?
Schneider Electric's HMISTO705 touch panel combines advanced technology with rugged design to offer a reliable and efficient solution for industrial control and automation. Its user-friendly interface, versatile connectivity options, and robust build quality make it an excellent choice for enhancing operational control in various applications.
Explore the Schneider HMISTO705 today and experience the perfect blend of performance, reliability, and ease of use.
range of product |
Magelis STO & STU
|
|
---|---|---|
product or component type |
Touch panel screen
|
|
software designation |
Vijeo XD
|
|
operating system |
Magelis
|
display size |
4.3 inch
|
|
---|---|---|
display type |
Colour TFT LCD
|
|
display colour |
65536 colours
|
|
display resolution |
480 x 272 pixels
|
|
touch panel |
Analogue
|
|
backlight lifespan |
50000 hours with white
|
|
brightness |
16 levels via touch panel
|
|
character font |
Taiwanese (traditional Chinese)
Cyrillic ASCII (European characters) Japanese (ANK, Kanji) Korean Chinese (simplified Chinese) |
|
[Us] rated supply voltage |
12...24 V DC - 10...20 %
|
|
power consumption in W |
7.5 W
|
|
number of pages |
8999
|
|
memory description |
Application memory, 26 MB
Back up of data, 512 kB |
|
integrated connection type |
1 USB 2.0 type mini B
1 USB 2.0 type A 1 9-pin terminal block connector serial link with RS232C interface at 2400...115200 bps |
|
supply |
External source
|
|
realtime clock |
With RTC-battery set (optional)
|
|
downloadable protocols |
Third party protocols
Modbus |
|
range compatibility |
MitsubishI
Allen-Bradley Siemens Omron |
|
fixing mode |
By 2 installation fasteners on 1.5 to 6 mm thick panel
|
|
enclosure material |
PPT
|
|
front material |
Plastic
|
|
cut-out dimensions |
77.5 x 112.5 mm
66 x 105 mm (with mounting adaptor) |
|
product weight |
0.22 kg
|
standards |
CSA C22.2 No 142
EN 61131-2 EN 61000-6-4 UL 61010-1 ANSI/ISA 12.12.01 UL 61010-2-201 EN 61000-6-2 CSA C22.2 No 213 |
|
---|---|---|
product certifications |
UL
C-Tick ATEX zone 2/22 CE KCC CUL |
|
directives |
2002/96/EC - WEEE directive
2002/95/EC - RoHS directive 1907/2006/EC - REACH directive |
|
ambient air temperature for operation |
0...50 °C
|
|
ambient air temperature for storage |
-20...60 °C
|
|
relative humidity |
10...90 % without condensation
|
|
operating altitude |
2000 m
|
|
IP degree of protection |
IP20 (rear panel)
IP65f (front panel) |
|
NEMA degree of protection |
NEMA 4X/13 front panel (indoor use)
|
|
shock resistance |
15 gn for 11 ms conforming to IEC 61131-2
|
|
vibration resistance |
1 gn (f = 5...150 Hz) conforming to IEC 61131-2
3.5 mm constant amplitude (f = 5...150 Hz) conforming to IEC 61131-2 |
|
electromagnetic compatibility |
Resistance to radiated electromagnetic fields : 10 V/m 80
MHz...2.7 GHz
Resistance to electrostatic discharge : 8 kV air discharge conforming to EN 61000-4-2 level 3 Resistance to electrostatic discharge : 6 kV direct contact conforming to EN 61000-4-2 level 3 |
Schneider HMISTO705 4.3" Wide Screen Touch Panel with RS-232 Terminal Block
- Brand: Schneider
- Product Code: HMISTO705
- Availability: 1000
