Panasonic MINAS A6 MHMF012L1D4M Servo Motor 200V 100W
The Panasonic MINAS A6 MHMF012L1D4M Servo Motor epitomizes precision engineering, combining cutting-edge technology with unparalleled performance. Engineered for efficiency and reliability, this servo motor is designed to meet the exacting demands of industrial applications.
Key Features:
High Precision Control: The MINAS A6 servo motor delivers exceptional precision control, ensuring accurate motion and positioning within even the most intricate operations.
Compact Design: Its compact structure, despite its robust power output, makes it an ideal choice where space optimization is critical.
200V Power Supply: Operating at 200 volts, this servo motor offers enhanced power while maintaining energy efficiency, reducing operational costs.
100W Power Output: With a power output of 100 watts, this motor provides consistent and reliable performance across various industrial settings.
Durability and Reliability: Built to withstand challenging environments, the MHMF012L1D4M servo motor guarantees longevity and sustained performance.
Advanced Technology: Leveraging state-of-the-art technology, the MINAS A6 series ensures seamless integration with control systems for optimized functionality.
Applications:
- Industrial Automation
- Robotics
- CNC Machining
- Packaging Machinery
- Printing Equipment
Technical Specifications:
- Model: MHMF012L1D4M
- Input Voltage: 200V
- Power Output: 100W
- Type: Servo Motor
- Manufacturer: Panasonic
- Compatibility: Compatible with a wide range of control systems for versatile integration.
SEO Optimization:
To optimize search engine visibility, this description includes relevant keywords such as "Panasonic MINAS A6," "Servo Motor," "200V," and "100W." These keywords are strategically placed within the content to enhance discoverability without compromising the readability and comprehensiveness of the description.
Invest in the Panasonic MINAS A6 MHMF012L1D4M Servo Motor to elevate your industrial operations with unparalleled precision, reliability, and efficiency.
Spec Detail
| Item | Specifications |
|---|---|
| Part Number | MHMF012L1D4M |
| Details | High inertia, Lead wire type |
| Family Name | MINAS A6 |
| Series | MHMF Series |
| Type | High inertia |
| Special Order Product | Special Order Product |
| Cautions for Special ordering product | Please avoid the motor, or equipment containing the motor to be distributed to Japan, or other regions through Japan. |
| Enclosure | IP65 |
| About Enclosure | Except rotating portion of output shaft and leadwire end. |
| Environmental Conditions | For more details, please refer to the instruction manual. |
| Flange sq. dimension | 40 mm sq. |
| Flange sq. dimension (Unit:mm) | 40 |
| Motor lead-out configuration | Lead wire |
| Motor encoder connector | Lead wire |
| Power supply capacity (kVA) | 0.5 |
| Voltage specifications | 200 V |
| Rated output | 100 W |
| Rated current (A (rms)) | 1.1 |
| Holding brake | with |
| Mass (kg) | 0.65 |
| Oil seal | with protective lip |
| Shaft | Round |
| Rated torque (N ⋅ m) | 0.32 |
| Continuous stall torque (N ⋅ m) | 0.33 |
| Momentary Max. peak torque (N ⋅ m) | 1.11 |
| Max. current (A (o-p)) | 5.5 |
| Regenerative brake frequency (times/min) | Without option :No limit With option :No limit Option (External regenerative resistor) Part No. : DV0P4281 |
| About regenerative brake frequency | Please refer to the details of [Motor Specification Description] , Note: 1, and 2. |
| Rated rotational speed (r/min) | 3000 |
| Rated rotational Max. speed (r/min) | 6500 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) | 0.074 |
| Recommended moment of inertia ratio of the load and the rotor | 30 times or less |
| About recommended moment of inertia ratio of the load and the rotor | Please refer to the details of [Motor Specification Description] ,Note: 3. |
| Rotary encoder: specifications | 23-bit Absolute/Incremental system |
| Notice | When using a rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder. |
| Rotary encoder: Resolution | 8388608 |
Brake specifications
| Item | Specifications |
|---|---|
| Static friction torque (N ⋅ m) | 0.38 or more |
| Engaging time (ms) | 35 or less |
| Releasing time (ms) | 20 or less |
| Exciting current (DC) (A) | 0.30 |
| Releasing voltage (DC) (V) | 1 or more |
| Exciting voltage (DC) (V) | 24 ± 2.4 |
| About brake specifications | This brake will be released when it is energized. Do not use this for braking the motor in motion. Please refer to the details of [Motor Specification Description] , "Specifications of Built-in Holding Brake" and "Notes on [Motor specification] page, Note: 4. |
Permissible load
| Item | Specifications |
|---|---|
| During assembly: Radial load P-direction (N) | 147 |
| During assembly: Thrust load A-direction (N) | 88 |
| During assembly: Thrust load B-direction (N) | 117.6 |
| During operation: Radial load P-direction (N) | 68.6 |
| During operation: Thrust load A, B-direction (N) | 58.8 |
| About permissible load | For details, refer to the [Motor Specification Description] "Permissible Load at Output Shaft". |
