Sanyo Denki R2AA08020FXH03M AC Servo Motor – 0.2kW, 6000RPM
Overview:
The Sanyo Denki R2AA08020FXH03M AC Servo Motor is a high-performance, compact motor designed for precision control in demanding applications. With a power rating of 0.2kW and a maximum speed of 6000 RPM, this servo motor offers exceptional efficiency and reliability, making it ideal for automation, robotics, and advanced machinery.
Key Features:
High Power Density: The R2AA08020FXH03M provides a robust 0.2kW output, ensuring reliable performance even in high-load applications. Its compact design allows for easy integration into space-constrained environments.
High-Speed Operation: Capable of reaching speeds up to 6000 RPM, this servo motor supports rapid and precise movements, crucial for high-speed manufacturing processes and dynamic operations.
Advanced Control Technology: The motor features advanced feedback and control systems, ensuring smooth and accurate motion control. This technology minimizes errors and enhances operational efficiency.
Robust Construction: Built to withstand harsh industrial environments, the R2AA08020FXH03M is engineered with high-quality materials and components that offer durability and longevity.
Energy Efficiency: With optimized energy consumption, this servo motor reduces operational costs and minimizes energy waste, contributing to a greener and more cost-effective operation.
Versatile Applications: Ideal for use in CNC machinery, conveyor systems, packaging equipment, and more. Its versatility makes it a valuable component for a wide range of industrial applications.
Technical Specifications:
- Model: R2AA08020FXH03M
- Power Rating: 0.2kW
- Maximum Speed: 6000 RPM
- Type: AC Servo Motor
- Feedback Type: High-precision encoder
- Cooling Method: Air-cooled
- Mounting Type: Standard flange
Applications:
The Sanyo Denki R2AA08020FXH03M AC Servo Motor excels in various applications, including:
- Automation Systems: Enhances the precision and speed of automated processes.
- Robotics: Provides reliable and accurate control for robotic arms and systems.
- CNC Machines: Delivers consistent performance for milling, turning, and other CNC operations.
- Packaging Machinery: Ensures fast and accurate packaging and labeling.
Why Choose the Sanyo Denki R2AA08020FXH03M?
Choosing the Sanyo Denki R2AA08020FXH03M means investing in a high-quality servo motor that offers exceptional performance, reliability, and efficiency. Its advanced technology and robust design make it a superior choice for applications requiring precise control and high-speed operation.
- Model No.
- R2AA08020FXH03M
- Motor classification
- Rotary (Medium inertia)
- Motor flange size[mm]
- 80
- Rated output[kW]
- 0.2
- Rated speed [min-1]
- 3000
- Max. speed [min-1]
- 6000
- Rated torque [N·m]
- 0.637
- Continuous stall torque [N·m]
- 0.686
- Peak stall torque [N·m]
- 2.2
- Rotor inertia [×10-4kg·m2 (GD2/4)]
- 0.52
- Encoder type
- Single-turn absolute
- Encoder Resolution [P/R]
- 17-bit
- Output shaft
- Straight
- Connection
- Cable (without connector)
- Oil seal
- No
- Protection rating
- IP65
- Safety functions
- No
- Operating temperature range
- 0～40℃
- Operating humidity range
- 90% max. (non-condensing)
