• Mitsubishi ST1DA2-V ST Series Analog Output Module

Product Description

Mitsubishi ST1DA2-V ST Series Analog Output Module

The Mitsubishi ST1DA2-V ST Series Analog Output Module is engineered for precision and reliability in advanced industrial automation systems. This module features high-performance analog output capabilities, designed to meet the rigorous demands of modern manufacturing environments.

Key Features:

  • Analog Output Channels: The ST1DA2-V module provides 2 high-resolution analog output channels, allowing for accurate and stable signal transmission to control various devices.
  • Output Range: Each channel supports a wide output range, ensuring compatibility with diverse applications requiring precise analog signal outputs.
  • Resolution: With a high resolution, the ST1DA2-V guarantees fine granularity and control, making it suitable for applications that demand exacting standards.
  • Temperature Stability: The module is engineered with advanced temperature compensation features to maintain accuracy in varying environmental conditions.
  • Integration: Designed for seamless integration with Mitsubishi’s ST Series PLCs, the module supports easy installation and configuration, enhancing overall system efficiency.
  • Robust Design: Built to withstand harsh industrial environments, the ST1DA2-V boasts a durable construction that ensures long-term reliability and performance.

Applications: The Mitsubishi ST1DA2-V ST Series Analog Output Module is ideal for applications in manufacturing processes, automotive systems, and other industrial sectors where precise analog signal output is critical. It is well-suited for use in systems requiring accurate control of actuators, sensors, and other devices that rely on analog signals.

Specifications:

  • Channels: 2
  • Output Type: Voltage/Current
  • Resolution: High
  • Temperature Range: Wide
  • Compatibility: Mitsubishi ST Series PLCs

Elevate your automation processes with the Mitsubishi ST1DA2-V ST Series Analog Output Module, designed to deliver unparalleled performance and reliability.

Mitsubishi ST1DA2-V ST Series Analog output module, 2 Outputs, Voltage

  ANALOGUE I/O MODULE
Type ST SERIES
Power Supply (V) 24
Current Type DC
Occupied Stations 2
Integrated Analogue Outputs 2
Output Voltage Range (V) -10-10; 0-10; 0-5; 1-5
Wiring SPRING/SCREW CLAMP
Int. Current Consumption (A) 0,095
PRODUCT DIMENSIONS & WEIGHT
Width (mm) 12,6
Height (mm) 77,6
Depth (mm) 55,4
Weight (kg) 0,04
ORDER CODES
European Order Code 152975
Global Order Code 1WP502
CLASSIFICATION DATA
Product hierarchy IAD50303
Class Description FA-MOD PLC: Analogue I/O Module
External Material Group Standard Material
AVAILABILITY
Logistic Class B
PACKAGING DIMENSIONS & WEIGHT
Gross Weight 0.044  KG
Volume 0.096  CDM
Length 8 CM
Width 6 CM
Height 2 CM
COMMODITY / IMPORT CODE
Commodity Code 85371098
Country of Origin JP
LIFE CYCLE
Predecessor 68912
Successor 217631  ST1DA2-V-F01
CAMPAIGNS
Selling Status Standard
ENVIRONMENTAL

RoHS Compliance COMPLIANT
REACH Limit Exceeded NO
Dangerous Goods Regulations NO

Mitsubishi ST1DA2-V ST Series Analog Output Module

  • Brand: Mitsubishi
  • Product Code: ST1DA2-V
  • Availability: 1000

Tags: Mitsubishi, ST1DA2-V, Analog Output Module, ST Series, Industrial Automation, High-Resolution Output, Mitsubishi PLC
