Schneider TSXDEY16A3C Discrete Input Module - 16 Capacitive Isolated - 110V AC - 12mA
Overview
The Schneider TSXDEY16A3C Discrete Input Module is a high-performance, industrial-grade input solution designed to integrate seamlessly into Schneider Electric's Modicon Premium PLC systems. This module features 16 channels of capacitive isolation, ensuring reliable and precise signal processing in demanding automation environments.
Key Features
16 Capacitive Isolated Inputs: Provides 16 discrete input channels with capacitive isolation, effectively minimizing electrical noise and interference. Each input is independently isolated to protect against high-voltage spikes and signal contamination.
Voltage Rating: Compatible with 110V AC input signals, making it suitable for interfacing with a variety of industrial sensors and devices that operate at this standard voltage level.
Current Consumption: Each input channel operates with a low current requirement of just 12mA, ensuring efficient energy consumption and minimal impact on your system’s power budget.
Robust Construction: Designed for durability and reliability, the TSXDEY16A3C is engineered to withstand harsh industrial conditions, including vibrations, temperature fluctuations, and electrical disturbances.
High-Quality Isolation: The capacitive isolation technology ensures that each input is electrically separated from the system, providing enhanced protection against electrical faults and improving overall system stability.
Easy Integration: Seamlessly integrates with Schneider Electric's Modicon Premium PLC systems, ensuring straightforward installation and compatibility with existing automation setups.
Enhanced Signal Integrity: Delivers accurate and stable input readings, crucial for maintaining the performance and safety of your industrial processes.
Applications
The Schneider TSXDEY16A3C is ideal for a wide range of applications, including:
Industrial Automation: Perfect for use in automated manufacturing processes where reliable and isolated input signals are essential.
Control Systems: Suitable for control panels and systems requiring discrete input from various sensors and switches operating at 110V AC.
Safety Systems: Can be employed in safety-critical applications where isolation and signal integrity are paramount.
Specifications
- Model Number: TSXDEY16A3C
- Input Channels: 16
- Input Type: Capacitive Isolated
- Input Voltage: 110V AC
- Input Current: 12mA per Channel
- Isolation Type: Capacitive
- Compatibility: Modicon Premium PLC systems
Why Choose Schneider TSXDEY16A3C?
The Schneider TSXDEY16A3C Discrete Input Module offers a robust solution for reliable and precise input signal processing. Its capacitive isolation ensures exceptional protection and stability, making it an ideal choice for demanding industrial environments. Experience enhanced performance, ease of integration, and superior reliability with Schneider Electric's cutting-edge technology.
range of product |
Modicon Premium Automation platform
|
|
---|---|---|
product or component type |
Discrete input module
|
|
discrete input number |
16 capacitive isolated conforming to EN/IEC 61131-2 type 2
|
|
discrete input voltage |
110 V AC
|
|
network frequency |
50/60 Hz 47...63 Hz AC
|
|
sensor power supply |
85...132 V
|
|
input compatibility |
With 2-wire/3-wire proximity sensors conforming to EN/IEC
60947-5-2
|
|
discrete input current |
12 mA
|
voltage state 1 guaranteed |
74 V
|
|
---|---|---|
current state 1 guaranteed |
6 mA
|
|
voltage state 0 guaranteed |
20 V
|
|
current state 0 guaranteed |
4 mA
|
|
input impedance |
9200 Ohm at state 1
|
|
response time |
<= 20 ms
10 ms |
|
isalotion resistance |
< 10 MOhm 500 V DC
|
|
power dissipation |
0.83 W
|
|
electrical connection |
Screw terminal
|
|
marking |
CE
|
|
current consumption |
80 mA 5 V DC
|
|
module format |
Standard
|
|
product weight |
0.32 kg
|
dielectric strength |
1500 V AC at 50/60 Hz
|
|
---|---|---|
standards |
73/23/EEC
89/336/EEC 92/31/EEC 93/68/EEC CSA C22.2 No 142 EN/IEC 61131-2 IEC 60664 UL 508 CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 213 Class I Division 2 Group C CSA C22.2 No 213 Class I Division 2 Group D |
|
product certifications |
ABS
BV DNV GL LR RINA RMRS |
|
ambient air temperature for operation |
0...60 °C
|
|
ambient air temperature for storage |
-25...70 °C
|
|
relative humidity |
10...95 % without condensation for operation
5...95 % without condensation for storage |
|
operating altitude |
0...2000 m
|
|
protective treatment |
Conformal coating Humiseal 1A33
TC |
|
IP degree of protection |
IP20
|
|
pollution degree |
2
|
