Schneider TSXDSY08T2C Discrete Output Module for Modicon Premium
  • Brand: Schneider
  • Product Code: TSXDSY08T2C
1000 |

Ex Tax: $0.00
Loading...

Description

Schneider TSXDSY08T2C Discrete Output Module for Modicon Premium Series

Overview: The Schneider TSXDSY08T2C Discrete Output Module is a high-performance component designed to seamlessly integrate with the Modicon Premium series, providing robust control capabilities for industrial automation applications. Engineered with precision and reliability in mind, this module empowers users to effectively manage and manipulate discrete signals, enhancing operational efficiency and productivity.

Key Features:

  • Compatibility: Specifically engineered for integration with the Modicon Premium series, ensuring seamless interoperability and optimal performance within the system.
  • Discrete Output Channels: Equipped with 8 discrete output channels, allowing for precise control and manipulation of connected devices and processes.
  • High Reliability: Constructed with high-quality materials and advanced engineering techniques, guaranteeing long-term reliability and durability even in demanding industrial environments.
  • Flexible Configuration: Offers flexible configuration options to accommodate diverse application requirements, enabling users to tailor the module to their specific needs.
  • Diagnostic Capabilities: Incorporates advanced diagnostic features for proactive monitoring and troubleshooting, facilitating rapid identification and resolution of potential issues.
  • Easy Installation: Designed for easy integration and installation, minimizing downtime and simplifying the deployment process for enhanced operational efficiency.

Technical Specifications:

  • Model: TSXDSY08T2C
  • Number of Channels: 8 discrete output channels
  • Input Voltage: [Input Voltage Range]
  • Output Voltage: [Output Voltage Range]
  • Operating Temperature: [Operating Temperature Range]
  • Dimensions: [Dimensions in mm/inches]
  • Weight: [Weight in kg/lbs]
  • Certifications: [Certifications, e.g., CE, UL]

Applications:

  • Industrial Automation: Ideal for controlling various industrial processes and machinery, ranging from manufacturing and assembly lines to packaging and material handling systems.
  • Building Automation: Well-suited for building automation systems, enabling efficient management of lighting, HVAC, and security systems.
  • Energy Management: Enables precise control over energy consumption by managing the operation of equipment and devices based on demand and scheduling.

SEO Keywords: Discrete Output Module, Schneider TSXDSY08T2C, Modicon Premium, Industrial Automation, Control Module, Industrial Control, Schneider Electric, Automation Solutions, Programmable Logic Controller, PLC Module, High-Performance Output Module.

Conclusion: The Schneider TSXDSY08T2C Discrete Output Module stands as a testament to Schneider Electric's commitment to delivering innovative and reliable solutions for industrial automation. With its advanced features, robust construction, and seamless integration capabilities, this module offers unparalleled control and flexibility, empowering users to optimize their processes and drive greater operational efficiency. Invest in the Schneider TSXDSY08T2C today to unlock the full potential of your automation systems.

For more information and to purchase the Schneider TSXDSY08T2C Discrete Output Module, contact us today.

Schneider TSXDSY08T2C Discrete output module - 8 solid state protected output - 24 V DC - 500 mA

Main
range of product
Modicon Premium Automation platform
product or component type
Discrete output module
discrete output number
8
discrete output type
Solid state protected
discrete output voltage
24 V DC positive conforming to EN/IEC 61131-2 19...30 V
discrete output current
500 mA
Complementary
current per channel
<= 0.625 A
current per module
<= 4 A
leakage current
< 0.5 mA at state 0
[Ures] residual voltage
< 1.2 V
response time
1.2 ms
switching frequency
0.5/LI² Hz
output overvoltage protection
By transil diode
reverse polarity protection
Reverse mounted diode
output overload protection
Electronic tripping on reactivation
short-circuit protection
Electronic tripping on reactivation
preactuator voltage detection threshold
16 V
load impedance
>= 48 W
isalotion resistance
> 10 MOhm 500 V
power dissipation
(1 W + 0.75 W x No of outputs x current per module)
marking
CE
electrical connection
Screw terminal block
current consumption
55 mA 5 V DC
module format
Standard
product weight
0.32 kg

Environment
dielectric strength
1500 V 50/60 Hz 60 s
standards
73/23/EEC
89/336/EEC
92/31/EEC
93/68/EEC
CSA C22.2 No 142
IEC 61131-2
UL 508
CSA C22.2 No 213 Class I Division 2 Group A
CSA C22.2 No 213 Class I Division 2 Group B
CSA C22.2 No 213 Class I Division 2 Group C
CSA C22.2 No 213 Class I Division 2 Group D
product certifications
ABS
BV
DNV
GL
LR
RINA
RMRS
ambient air temperature for operation
0...60 °C
ambient air temperature for storage
-25...70 °C
relative humidity
10...95 % without condensation for operation
5...95 % without condensation for storage
operating altitude
0...2000 m
protective treatment
Conformal coating Humiseal 1A33
TC
IP degree of protection
IP20
pollution degree
2
