Schneider TSXP574823AMC Double-format PL7 Processor - Transparent Ready - 1440 mA
Overview: The Schneider TSXP574823AMC is a high-performance Double-format PL7 processor engineered for robust industrial automation applications. This advanced processor excels in delivering precision control and seamless integration with transparent processing capabilities, making it an ideal choice for complex automation tasks requiring high reliability and efficiency.
Key Features:
Double-format Compatibility: The TSXP574823AMC supports dual-format operations, providing flexibility and adaptability to diverse industrial environments. It ensures smooth transitions and compatibility with various programming environments and applications.
Transparent Ready Technology: Designed with transparency in mind, this processor offers transparent communication capabilities that facilitate real-time data exchange and monitoring. This feature enhances operational transparency and simplifies integration with existing systems.
High Power Output: With a robust 1440 mA power supply capability, the TSXP574823AMC ensures reliable performance and stable operation even under demanding conditions. This high power output supports extensive I/O modules and peripherals, making it suitable for large-scale automation projects.
Advanced Processing Power: Equipped with cutting-edge processing technology, the TSXP574823AMC delivers superior computational performance, enabling rapid processing of complex algorithms and data. This results in improved system responsiveness and efficiency.
Durable and Reliable: Constructed to withstand the rigors of industrial environments, the TSXP574823AMC features a rugged design that ensures long-term durability and consistent performance. Its high-quality build guarantees reliable operation in harsh conditions.
Technical Specifications:
- Model: Schneider TSXP574823AMC
- Processor Type: Double-format PL7
- Power Supply: 1440 mA
- Communication Technology: Transparent Ready
- Compatibility: Dual-format operation
Applications:
The Schneider TSXP574823AMC is ideal for a wide range of applications, including:
- Industrial Automation Systems: Perfect for controlling and automating industrial processes with high precision and reliability.
- Complex Data Processing: Suitable for environments requiring advanced data processing and real-time monitoring.
- Integration Projects: Excellent for projects that demand seamless integration with existing automation infrastructure.
Why Choose Schneider TSXP574823AMC?
The Schneider TSXP574823AMC stands out for its advanced processing capabilities, transparency-ready technology, and high power output. It provides an optimal solution for demanding automation tasks, ensuring efficiency, reliability, and adaptability in various industrial applications.
Upgrade your automation systems with the Schneider TSXP574823AMC Double-format PL7 Processor and experience unparalleled performance and flexibility.
| range of product |
Modicon Premium Automation platform
|
|
|---|---|---|
| product or component type |
Double-format PL7 processor
|
|
| software designation |
PL7 Junior/Pro
|
| concept |
Transparent Ready
|
|
|---|---|---|
| number of racks |
16 4/6/8 slots
8 12 slots |
|
| number of slots |
128
64 96 |
|
| discrete I/O processor capacity |
2040 I/O
|
|
| analogue I/O processor capacity |
256 I/O
|
|
| number of application specific channel |
<= 64
|
|
| number of process control channel |
<= 20 up to 60 simple loops
|
|
| integrated connection type |
Fipio manager (127 agents) SUB-D 9
Ethernet TCP/IP RJ45 10/100 Mbit/s Non isolated serial link 2 female mini DIN 19.2/115 kbit/s |
|
| communication module processor capacity |
1 CANopen
4 network module 2 fieldbus modules (1 if CANopen used) 8 AS-Interface bus modules |
|
| memory description |
Internal RAM (with PCMCIA card) 176 Kwords data
Internal RAM (without PCMCIA card) 96 Kwords program and data PCMCIA card 2048 Kwords additional data storage PCMCIA card 992 Kwords program |
|
| maximum size of object areas |
30.5 %MWi internal words located internal data
32 %KWi constant words located internal data 32768 %Mi located internal bits |
|
| application structure |
1 fast task
1 master task 64 event tasks |
|
| execution time per instruction |
0.06 µs Boolean with PCMCIA card
0.06 µs Boolean without PCMCIA card 0.08 µs word or fixed-point arithmetic with PCMCIA card 0.08 µs word or fixed-point arithmetic without PCMCIA card 1.7 µs floating points with PCMCIA card 1.7 µs floating points without PCMCIA card |
|
| number of instructions per ms |
13.82 Kinst/ms 100 % Boolean with PCMCIA card
13.82 Kinst/ms 100 % Boolean without PCMCIA card 8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card 8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card |
|
| system overhead |
0.22 ms fast task
1.15 ms master task |
|
| marking |
CE
|
|
| local signalling |
1 LED green Ethernet TCP/IP port ready (RUN)
1 LED green processor running (RUN) 1 LED red activity on Fipio bus (FIP) 1 LED red collision detection (COL) 1 LED red Ethernet TCP/IP port fault (ERR) 1 LED red I/O module or configuration fault (I/O) 1 LED red processor or system fault (ERR) 1 LED yellow activity on the terminal port (TER) 1 LED yellow Ethernet link diagnostics (STS) 1 LED yellow reception activity (RX) 1 LED yellow transmission activity (TX) |
|
| current consumption |
1440 mA 5 V DC
|
|
| module format |
Double
|
| standards |
73/23/EEC
89/336/EEC 92/31/EEC 93/68/EEC CSA C22.2 No 142 IEC 61131-2 UL 508 CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 213 Class I Division 2 Group C CSA C22.2 No 213 Class I Division 2 Group D |
|
|---|---|---|
| product certifications |
ABS
BV DNV GL LR RINA RMRS |
|
| ambient air temperature for operation |
0...60 °C
|
|
| ambient air temperature for storage |
-25...70 °C
|
|
| relative humidity |
10...95 % without condensation for operation
5...95 % without condensation for storage |
|
| operating altitude |
0...2000 m
|
|
| protective treatment |
Conformal coating Humiseal 1A33
TC |
|
| IP degree of protection |
IP20
|
|
| pollution degree |
2
|
