Schneider VW3A7752 Braking Resistor – 28 Ohms – 5.1 kW – IP23
Enhance Your Drive System’s Performance with Precision Engineering
The Schneider VW3A7752 Braking Resistor is engineered to deliver superior performance and reliability in demanding industrial environments. With a resistance value of 28 ohms and a power rating of 5.1 kW, this high-quality braking resistor is designed to ensure optimal functionality and protection for your drive system.
Key Features:
Resistance Value: 28 Ohms
The VW3A7752’s resistance value is precisely engineered to manage and dissipate excess energy effectively, ensuring your drive system operates within safe parameters and enhancing overall system performance.Power Rating: 5.1 kW
With a robust power rating of 5.1 kW, this braking resistor provides reliable energy absorption and heat dissipation, crucial for maintaining system stability and efficiency during dynamic braking applications.Protection Class: IP23
The IP23 rating guarantees effective protection against ingress of water and solid objects, making this resistor suitable for use in environments where exposure to moisture and dust is minimal.Durable Construction:
Built with high-quality materials, the VW3A7752 is designed to withstand the rigors of industrial applications, offering long-term durability and consistent performance.
Applications:
The Schneider VW3A7752 Braking Resistor is ideal for use in a variety of industrial applications, including but not limited to:
Variable Frequency Drives (VFDs):
Enhance the braking capabilities of your VFDs, ensuring smooth and controlled stopping of motors.Elevator Systems:
Manage regenerative braking energy efficiently, contributing to safe and reliable elevator operations.Cranes and Hoists:
Provide effective braking in lifting and lowering operations, improving safety and performance.Machine Tools:
Maintain precise control during dynamic braking processes in various machine tools.
Benefits:
Improved System Reliability:
By managing excess energy and preventing overheating, the VW3A7752 contributes to the longevity and reliability of your drive system.Enhanced Safety:
Effective energy dissipation reduces the risk of system failures and enhances overall safety during operation.Efficient Performance:
The resistor’s design ensures optimal performance, even under the most demanding conditions, supporting smooth and efficient braking.
Why Choose Schneider?
Schneider Electric is renowned for its commitment to innovation and quality in industrial automation and control solutions. The VW3A7752 Braking Resistor is a testament to this commitment, offering unparalleled performance and durability for critical applications.
Order Your Schneider VW3A7752 Braking Resistor Today
Elevate your system’s performance and reliability with the Schneider VW3A7752 Braking Resistor. For more information or to place an order, contact us today. Experience the precision and excellence that only Schneider Electric can provide.
Schneider VW3A7752 Braking resistor - 28 ohms - 5.1 kW - IP23
| product or component type |
Braking resistor
|
|---|
| range compatibility |
Altivar Machine ATV340
Altivar Process ATV900 |
|
|---|---|---|
| product compatibility |
Variable speed drive ATV930 wall mount 11 kW 380...480 V severe
cycle
Variable speed drive ATV930 wall mount 15 kW 380...480 V severe cycle Variable speed drive ATV930 wall mount 4 kW 200...240 V severe cycle Variable speed drive ATV950 wall mount 11 kW 380...480 V severe cycle Variable speed drive ATV950 wall mount 15 kW 380...480 V severe cycle Variable speed drive ATV340 7.5 kW 380...480 V severe cycle Variable speed drive ATV340 11 kW 380...480 V severe cycle Variable speed drive ATV930 15 kW 500...690 V severe cycle Variable speed drive ATV930 18.5 kW 500...690 V severe cycle Variable speed drive ATV930 20 hp 600 V severe cycle Variable speed drive ATV930 25 hp 600 V severe cycle |
|
| braking cycle |
Severe cycle (heavy duty) : <= 54 s braking with 100 % braking
torque for a 120 s cycle
Severe cycle (heavy duty) : <= 6 s braking with 165 % braking torque for a 120 s cycle |
|
| average power available |
5.1 kW at 50 °C
|
|
| ohmic value |
28 Ohm
|
|
| electrical connection |
Terminal, clamping capacity: <= 2.5 mm², AWG 12 for temperature
control switch
M6 bar wire for drive |
|
| protection type |
Thermal protection via drive or temperature control switch at
120 °C
|
|
| [Ue] rated operational voltage |
24 V DC
250 V AC |
|
| width |
540 mm
|
|
| height |
485 mm
|
|
| depth |
650 mm
|
|
| product weight |
27 kg
|
| ambient air temperature for operation |
0...50 °C
|
|
|---|---|---|
| ambient air temperature for storage |
-25...70 °C
|
|
| IP degree of protection |
IP23
|
Schneider VW3A7752 Braking resistor - 28 ohms - 5.1 kW - IP23
- Brand: Schneider
- Product Code: VW3A7752
- Availability: 1000
Tags: Schneider VW3A7752, Braking Resistor, 28 Ohms, 5.1 kW, IP23, Industrial Resistor, VFD Braking Resistor, Energy Dissipation, Schneider Electric
